IOMM AGZ-5 AGZ 026B through 130B 89
SET ALARM LMTS (3)
HighCondPr = XXXpsi
HiCondStgDn = XXXpsi
HighCondPr (the unit high-discharge-pressure shutdown) is a stop alarm that shuts off
the unit when the discharge pressure reaches the setting. The default setting is 385 psi.
The HiCondStDn is a limit alarm that unloads the unit in an attempt to prevent total
shutdown from the HighCondPr. The stage down is set at 370 psi.
SET ALARM LMTS (4)
PhaseVoltage=YES/NO
GroundFault=YES/NO
SET FAN STAGES
SET FANS SPs (1)
Number of Fans = X
Fan VFD = YES/NO
The Number of Fans line tells the controller the number of fans on the unit. The UP
ARROW toggles between 4, 6 and 8.
Fan VFD tells the controller whether the optional low ambient fan VFD is installed in
the unit. The UP ARROW toggles between YES and NO. The setting changes the
range available: YES = -2°F to 60°F, NO = 35°F to 60°F.
SET FANS SPs (2)
Stg Up Deadband(°
°°
°F)
Stg2 Stg3 Stg4
XX.X XX.X XX.X
SET FANS SPs (3)
Stg Dn Deadband(°
°°
°F)
Stg0 Stg1 Stg2 Stg3
XX.X XX.X XX.X XX.X
SET FANS SPs (4)
VFD Min Speed= XX%
VFD Max Speed= XXX%
SET FANS SPs (5)
Cond Sat Temp Target
Setpoint= XXX.X °
°°
°F
