90 AGZ 026B through 130B IOMM AGZ-5
SET FANS SPs (6)
# Fans On At Startup
>75°
°°
°F >90°
°°
°F >105°
°°
°F
123
Screen Definitions – TEST
The field test screens are only available when the unit is in TEST mode. Using these
screens, any digital output can be controlled manually.
TEST UNIT (1)
Alarm Signal=Off
EvapWaterPump=Off
TEST UNIT (2)
Liq Line Sol 1=Off
Compressor HG1=Off
1=Off 3=Off 5=Off
TEST UNIT (3)
Liq Line Sol 2=Off
Compressor HG2=Off
2=Off 4=Off 6=Off
TEST UNIT (4)
Fan 1= Off
Fan 3= Off
Fan 5/7= Off
TEST UNIT (5)
Fan 2= Off
Fan 4= Off
Fan 6/8= Off
TEST UNIT (6)
Fan VFD 1= 000.0%
Fan VFD 2= 000.0%
