36 AGZ 026B through 130B IOMM AGZ-5
Table 22, AGZ 075BM/BS – 130BM/BS, Electrical Wiring, Single Point
(Up to 105°F)
Power Supply Max. Fuse
Field Wire
AGZ Unit
Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Quantity
Wire
Gauge
75C
Recomm’d.
Fuse
Or HACR
Breaker
Size
Or HACR
Breaker
Size
208 358 6 4/0 400 400
230 358 6 4/0 400 400
380 187 3 3/0 225 225
460 150 3 1/0 175 175
075B
575 125 3 #1 150 150
208 380 6 250 450 450
230 380 6 250 450 450
380 219 3 250 250 250
460 171 3 2/0 200 200
085B
575 136 3 1/0 150 150
208 414 6 300 500 500
230 414 6 300 500 500
380 248 3 250 300 300
460 188 3 3/0 225 225
090B
575 146 3 1/0 175 175
208 463 6 350 500 500
230 463 6 300 500 500
380 260 3 300 300 300
460 199 3 3/0 225 225
100B
575 171 3 2/0 175 175
208 528 6 - (2) 300 600 600
230 528 6 - (2) 300 600 600
380 282 3 300 300 300
460 220 3 4/0 250 250
110B
575 182 3 3/0 200 200
208 613 6 - (2) 350 700 700
230 613 6 - (2) 350 700 700
380 323 3 400 350 350
460 248 3 250 250 250
120B
575 198 3 3/0 225 225
208 613 6 - (2) 350 700 700
230 613 6 - (2) 350 700 700
380 361 6 4/0 400 400
460 273 3 300 300 300
130B
575 212 3 4/0 225 225
NOTES:
1. Units operating in ambient temperatures of 95°F (35°C) and above must use the Maximum
Fuse or HACR Breaker size.
2. All Electrical Data notes are on page 49.
3. (2) indicates that two conduits are required.
4. Conduit hubs are not supplied.
