IOMM AGZ-5 AGZ 026B through 130B 37
Table 23, AGZ 075BM/BS – 130BM/BS, Compressor and Fan Motor Amps, Single and
Multi-Point (Up to 105°F)
Rated Load Amps Locked Rotor Amps
Compressors Compressors
Across-The-Line
AGZ
Unit
Size
Volts
No. 1 No. 3 No. 5 No. 2 No. 4 No. 6
F.L.
Amps
Fan
Motors
(Each)
No. Of
Fan
Motors
Fan
Motors
(Each)
No.1 No. 3 No. 5 No.2 No.4 No. 6
208 73.1 73.1 - 73.1 73.1 - 7.8 6 31.7 505 505 - 505 505 -
230 73.1 73.1 - 73.1 73.1 - 7.8 6 35.6 505 505 - 505 505 -
380 38.2 38.2 - 38.2 38.2 - 4.1 6 20.0 280 280 - 280 280 -
460 30.1 30.1 - 30.1 30.1 - 3.6 6 17.8 225 225 - 225 225 -
075B
575 25.2 25.2 - 25.2 25.2 - 3.0 6 14.0 180 180 - 180 180 -
208 73.1 73.1 - 83.3 83.3 - 7.8 6 31.7 505 505 - 500 500 -
230 73.1 73.1 - 83.3 83.3 - 7.8 6 35.6 505 505 - 500 500 -
380 38.2 38.2 - 52.5 52.5 - 4.1 6 20.0 280 280 - 305 305 -
460 30.1 30.1 - 39.0 39.0 - 3.6 6 17.8 225 225 - 250 250 -
085B
575 25.2 25.2 - 30.0 30.0 - 3.0 6 14.0 180 180 - 198 198 -
208 86.4 86.4 - 86.4 86.4 - 7.8 6 31.7 500 500 - 500 500 -
230 86.4 86.4 - 86.4 86.4 - 7.8 6 35.6 500 500 - 500 500 -
380 52.5 52.5 - 52.5 52.5 - 4.1 6 20.0 305 305 - 305 305 -
460 39.0 39.0 - 39.0 39.0 - 3.6 6 17.8 250 250 - 250 250 -
090B
575 30.0 30.0 - 30.0 30.0 - 3.0 6 14.0 198 198 - 198 198 -
208 52.8 52.8 52.8 74.5 74.5 74.5 7.8 8 31.7 425 425 425 505 505 505
230 52.8 52.8 52.8 74.5 74.5 74.5 7.8 8 35.6 425 425 425 505 505 505
380 32.7 32.7 32.7 39.8 39.8 39.8 4.1 8 20.0 239 239 239 280 280 280
460 23.7 23.7 23.7 30.6 30.6 30.6 3.6 8 17.8 187 187 187 225 225 225
100B
575 21.8 21.8 21.8 25.2 25.2 25.2 3.0 8 14.0 148 148 148 180 180 180
208 74.5 74.5 74.5 74.5 74.5 74.5 7.8 8 31.7 505 505 505 505 505 505
230 74.5 74.5 74.5 74.5 74.5 74.5 7.8 8 35.6 505 505 505 505 505 505
380 39.8 39.8 39.8 39.8 39.8 39.8 4.1 8 20.0 280 280 280 280 280 280
460 30.6 30.6 30.6 30.6 30.6 30.6 3.6 8 17.8 225 225 225 225 225 225
110B
575 25.2 25.2 25.2 25.2 25.2 25.2 3.0 8 14.0 180 180 180 180 180 180
208 87.9 87.9 87.9 88.0 88.0 88.0 7.8 8 31.7 505 505 505 500 500 500
230 87.9 87.9 87.9 88.0 88.0 88.0 7.8 8 35.6 505 505 505 500 500 500
380 39.8 39.8 39.8 52.5 52.5 52.5 4.1 8 20.0 280 280 280 305 305 305
460 30.6 30.6 30.6 39.0 39.0 39.0 3.6 8 17.8 225 225 225 250 250 250
120B
575 25.2 25.2 25.2 30.0 30.0 30.0 3.0 8 14.0 180 180 180 198 198 198
208 88.0 88.0 88.0 88.0 88.0 88.0 7.8 8 31.7 500 500 500 500 500 500
230 88.0 88.0 88.0 88.0 88.0 88.0 7.8 8 35.6 500 500 500 500 500 500
380 52.5 52.5 52.5 52.5 52.5 52.5 4.1 8 20.0 305 305 305 305 305 305
460 39.0 39.0 39.0 39.0 39.0 39.0 3.6 8 17.8 250 250 250 250 250 250
130B
575 30.0 30.0 30.0 30.0 30.0 30.0 3.0 8 14.0 198 198 198 198 198 198
All Electrical Data notes are on page 49.
