52 AGZ 026B through 130B IOMM AGZ-5
Figure 24, AGZ 075BS - 090BS Packaged Chiller
Y
Z
15.5
(392)
28.5 (724)
28.5
(724)
134.9 (3426)
X
100.4
(2550)
14.4
(364)
6.4
(162)
88.0 (2235)
43.8
(1111)
POWER ENTRY
POINT
0.875 KNOCK OUT
FIELD CONTROL
CONNECTION
12.4
(315)
12.
(315)
2.0
(51)
2.0
(51)
14.3
(364)
60.0 (1525)
110.1 (2797)
I
SO
LAT
O
R L
OC
ATI
O
N
S
O
N B
O
TT
O
M
O
F RAIL
COMPRESSORS CIRC. #1
COMPRESSORS CIRC. #2
INLET
OUTLET
Dwg. # 3305023
CONTROL
PANEL
CONTROL
PANEL
EVAPORATOR
Center of Gravity Inches (mm) Weights Lbs. (kg)
Unit Size
X Y Z
Evap Inlet &
Outlet Victaulic
in.
Shipping Weight Operating Weight
AGZ 075BS
44 (1118) 42 (1067) 60 (1524) 5 6320 (2867) 6530 (2962)
AGZ 085BS
43 (1092) 40 (1016) 60 (1524) 5 6480 (2939) 6690 (3035)
AGZ 090BS
44 (1118) 39 (991) 59 (1499) 5 6640 (3012) 6850 (3107)
