IOMM AGZ-5 AGZ 026B through 130B 53
Figure 25, AGZ 100BS - 130BS Packaged Chiller
"B"
"C"
33.7
(855)
25.2
(641)
67.8 (1721)
12.4 (315)
2.0
(51)
2.0
(51)
67.8 (1721)
INLET
"A"
OUTLET
"A"
COMPRESSORS CIRC. #1
COMPRESSORS CIRC. #2
ISOLATOR LOCATIONS ON BOTTOM OF RAIL
Z
Y
24.0
(610)
24.0
(610)
16.2
(410)
X
100.4
(
2550
)
88.0
(
2235
)
6.4 (162)
14.4 (365)
43.8
(
1111
)
POWER ENTRY POINT
0.875 KNOCK OUTS
FIELD CONTROL
CONNECTION
Dw
g
. # 3305024
EVAPORATOR
173.1 (4396)
CONTROL
PANEL
CONTROL
PANEL
Evaporator Water
Connections
Inches (mm)
Center of Gravity
Inches (mm)
Weights
Lbs. (kg)
Unit Size
Evap Inlet
& Outlet
Victaulic
“A” in.
B C X Y Z
Shipping
Weight
Operating
Weight
AGZ 100BS
5
14.8 (375.9) 93.5 (2374.9) 43 (1092) 43 (1092) 76 (1930) 7580 (3438) 7870 (3570)
AGZ 110BS
5
14. 8 (375.9) 93.5 (2374.9) 44 (1118) 43 (1092) 75 (1905) 7860 (3565) 8150 (3697)
AGZ 120BS
8
15.3 (388.6) 92.4 (2346.9) 43 (1092) 40 (1016) 75 (1905) 8380 (3801) 8720 (3955)
AGZ 130BS
8
15.3 (388.6) 92.4 (2346.9) 44 (1118) 38 (965) 74 (1880) 8710 (3951) 9050 (4105)
