IOMM AGZ-5 AGZ 026B through 130B 33
Electrical Data - Standard Ambient
Table 19, AGZ 026BM/BS – 070BM/BS, Electrical Data, Single Point
(105°F & below)
Power Supply
Field Wire
AGZ Unit
Size
Volts
Minimum
Circuit
Ampacity
(MCA)
Quantity
Wire
Gauge
75C
Recomm’d.
Fuse
Or HACR
Breaker
Size
Max. Fuse
Or HACR
Breaker
Size
208 133 3 1/0 150 150
230 126 3 #1 150 150
380 80 3 #4 90 90
460 68 3 #4 80 80
026B
575 52 3 #6 60 60
208 146 3 1/0 175 175
230 143 3 1/0 175 175
380 88 3 #3 100 100
460 74 3 #4 80 90
030B
575 58 3 #6 70 70
208 158 3 2/0 175 175
230 150 3 1/0 175 175
380 96 3 #3 110 110
460 79 3 #4 90 90
035B
575 64 3 #6 70 70
208 167 3 2/0 200 200
230 167 3 2/0 200 200
380 113 3 #2 125 125
460 81 3 #4 90 90
040B
575 70 3 #4 80 80
208 184 3 3/0 225 225
230 184 3 3/0 225 225
380 121 3 #1 125 125
460 94 3 #3 110 110
045B
575 78 3 #4 90 90
208 199 3 3/0 225 225
230 199 3 3/0 225 225
380 127 3 #1 150 150
460 104 3 #2 125 125
050B
575 86 3 #3 100 100
208 221 3 4/0 250 250
230 214 3 4/0 250 250
380 145 3 1/0 175 175
460 108 3 #2 125 125
055B
575 96 3 #3 110 110
208 248 3 250 300 300
230 228 3 4/0 250 250
380 156 3 2/0 175 175
460 112 3 #2 150 150
060B
575 105 3 #2 125 125
208 281 3 300 350 350
230 281 3 300 350 350
380 162 3 2/0 200 200
460 124 3 #1 150 150
065B
575 109 3 #2 125 125
208 301 3 350 350 350
230 301 3 350 350 350
380 168 3 2/0 200 200
460 130 3 #1 150 150
070B
575 112 3 #2 125 125
NOTES:
1. Units operating in ambient temperatures of 95°F (35°C) and above must use the
Maximum Fuse or HACR Breaker size.
2. All Electrical Data notes are on page 49.
3. Conduit hubs are not provided.
