42 AGZ 026B through 130B IOMM AGZ-5
Table 28, AGZ 065BM/BS - 130BM/BS, Electrical Data, Multi-Point (Up to 105°F)
Electrical Circuit #1 Electrical Circuit #2
Power
Supply
Power
Supply
Field Wire Field Wire
AGZ
Unit
Size
V
olts
Minimum
Circuit
Ampacity
(MCA)
Qty
Wire
Gauge
75C
Recomm’d
Fuse
or HACR
Breaker
Size
Max. Fuse
or HACR
Breaker
Size
Minimum
Circuit
Ampacity
(MCA)
Qty
Wire
Gauge
75C
Recomm’d
Fuse
or HACR
Breaker
Size
Max.
Fuse
or HACR
Breaker
Size
208 188 3 3/0 225 250 188 3 3/0 225 250
230 188 3 3/0 225 250 188 3 3/0 225 250
380 98 3 #3 110 125 98 3 #3 110 125
460 79 3 #4 90 110 79 3 #4 90 110
075B
575 66 3 #4 80 90 66 3 #4 80 90
208 188 3 3/0 225 250 218 3 4/0 250 300
230 188 3 3/0 225 250 218 3 4/0 250 250
380 98 3 #3 110 125 130 3 #1 150 175
460 79 3 #4 90 110 99 3 #3 125 125
085B
575 66 3 #4 80 90 77 3 #4 90 100
208 218 3 4/0 250 300 218 3 4/0 250 300
230 218 3 4/0 250 250 218 3 4/0 250 250
380 130 3 #1 150 175 130 3 #1 150 175
460 99 3 #3 125 125 99 3 #3 125 125
090B
575 77 3 #4 90 100 77 3 #4 90 100
208 203 3 4/0 250 250 273 3 300 300 300
230 203 3 3/0 225 225 273 3 300 300 300
380 123 3 #1 150 150 146 3 1/0 175 200
460 92 3 #3 110 110 114 3 #1 150 175
100B
575 83 3 #4 100 100 94 3 #3 110 125
208 273 3 300 300 300 273 3 300 300 300
230 273 3 300 300 300 273 3 300 300 300
380 146 3 1/0 175 175 146 3 1/0 175 175
460 114 3 #1 125 125 114 3 #1 125 125
110B
575 94 3 #3 110 110 94 3 #3 110 110
208 317 3 300 400 400 317 3 400 400 400
230 317 3 300 400 400 318 3 400 400 400
380 146 3 1/0 175 175 187 3 2/0 225 225
460 114 3 #1 125 125 141 3 1/0 175 175
120B
575 94 3 #3 110 110 110 3 #2 125 125
208 317 3 400 400 400 317 3 400 400 400
230 318 3 400 400 400 318 3 400 400 400
380 187 3 2/0 225 225 187 3 2/0 225 225
460 141 3 1/0 175 175 141 3 1/0 175 175
130B
575 110 3 #2 125 125 110 3 #2 125 125
NOTES:
1. All Electrical Data notes are on page 49.
2. Conduit hubs are not supplied.
