35
Application Information M5MSY-2010
How to Install the Air Filter
To Adjust the Vane Direction
Adjust the vane linkage as the direction shown to get the required vane direction.
Dimension of the Fresh Air Intake Hole
70.0
70.0
3.0
64.0
