Exploded View and Part List MWM-J-2009
INDOOR UNIT
MODEL: MWM009/015J/JR, M5WM010/015J/JR
Note: All exploded view and part list are subjected to change by the manufacturer without prior notice
No Description Part Number
1 Assy. Front Grille R50124099972
2 Panel, McQuay R50124099730
3
Disch. Grille Hor.Blade Assy. R50124096348
4 Assy. Bottom Frame R50124096340
5 Assy. Control Box
MWM009J R50044101234
MWM009JR R50044101233
M5WM010J R50044100232
M5WM010JR R50044100147
MWM/M5WM015J R50044100235
MWM/M5WM015JR R50044100231
6 Assy. Service Cover R50124096346
7 Assy. Piping Fixture R50124098515
8 Motor R03039030455
9 Motor Mounting Plate (1) R12014095347
10 Motor Mounting Plate (2) R12014095348
11 Blower R03029030446
12 Assy. Installation Plate R50014095316
13 Right Side Panel R12014095332
14 Cover, Drip Proof R12014095349
15 Clip, Coil Sensor R07054074446
No Description Part Number
16 Assy. Heat Exchanger
MWM/M5WM009/010J/JR R50024096739
MWM/M5WM015J/JR R50024096106
17 Assy. Drain Hose R50104096341
18 Fan Bearing Vibration
Absorber
R50124096342
19 Air Filter R12014095331
20 Bio Antibody Filter (Pack) R50129031334
Titanium Apatite Filter
(Pack)
R50129031447
21 Handset, Wireless G17
MWM009/015J R04084100290
MWM009/015JR R04084100289
M5WM010/015J R04084100290
M5WM010/015JR R04084100289
22 Control Module
MWM009J R04084101320
MWM009JR R04084101319
M5WM010J R04084100159
M5WM010JR R04084100158
MWM/M5WM015J R04084100155
MWM/M5WM015JR R04084100160
14_Exploded view.indd 6114_Exploded view.indd 61 3/31/2009 4:58:00 PM3/31/2009 4:58:00 PM
