McQuay Maverick I MPS006AG Series

IM 861
5
Figure 1: Bottom View
Figure 2: Cabinet Dimensions and Access Locations
Unit Dimensions
For clearances see page 9, Fgure 7. IMPORTANT: This unit
must be mounted level in both directions to allow water to drain
from the condenser section and condensate pan.
ST-A0801-11-00
ST-A0801-12
CONDENSER
COIL
BASE ELECTRICAL
ENTRY
BASE GAS
ENTRY
RETURN
SUPPLY
39.31
9.56
3.25
4.5
4.5
2.25
2
2
26
20
2
2
78.25
6.81
44.13
13.13
4.63
13.13
14.44
RETURN COVER/
OPTIONAL OUTDOOR
AIR HOOD LOCATION
CONDENSATE DRAIN
3/4” NPT FEMALE
BLOWER
ACCESS
COIL/FILTER
ACCESS
SUPPLY COVER
31.19
3.81
82.25
24.03
48.06
5.34
