MODEL : MCM050D / MLC050C
Indoor
DB
Indoor
WB
Capacit
y
Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 12.749 12.256 11.815 11.374 10.717 10.114 9.762 9.601 9.451
SC 11.176 11.014 10.869 10.724 10.104 9.535 9.204 9.052 8.910
15 TC 14.011 13.300 12.665 12.030 11.335 10.697 10.325 10.155 9.996
SC 10.996 10.774 10.575 10.377 9.777 9.227 8.906 8.760 8.622
18 TC 17.454 16.149 14.984 13.819 13.020 12.288 11.861 11.665 11.482
SC 10.505 10.119 9.775 9.431 8.886 8.386 8.095 7.961 7.836
19.4 TC 19.060 17.478 16.066 14.654 13.807 13.031 12.578 12.370 12.176
SC 10.275 9.814 9.402 8.990 8.470 7.994 7.716 7.589 7.469
20 TC 19.748 18.098 16.624 15.151 14.275 13.472 13.004 12.789 12.589
SC 10.177 9.681 9.238 8.796 8.287 7.821 7.549 7.425 7.308
22 TC 22.043 20.163 18.485 16.806 15.834 14.944 14.424 14.187 13.964
SC 9.849 9.239 8.694 8.149 7.678 7.246 6.994 6.879 6.771
24 TC 24.338 22.228 20.345 18.461 17.394 16.416 15.845 15.584 15.339
SC 9.522 8.797 8.149 7.502 7.068 6.670 6.439 6.332 6.233
MODEL : MCM061/ 062C / MLC061C
Indoor
DB
Indoor
WB Capacity
Outdoor
DB, °C
°C °C kW 19.4 25 30 35 40 46
26.7 13.9 TC 15.426 14.631 13.922 13.213 12.504 11.653
SC 15.426 14.631 13.922 13.213 12.504 11.653
15 TC 16.454 15.520 14.687 13.853 13.019 12.019
SC 14.771 14.033 13.374 12.714 12.055 11.264
18 TC 19.260 17.945 16.772 15.598 14.425 13.016
SC 12.987 12.401 11.878 11.354 10.830 10.202
19.4 TC 20.569 19.077 17.745 16.413 15.080 13.482
SC 12.155 11.639 11.179 10.719 10.259 9.707
20 TC 21.130 19.590 18.215 16.840 15.465 13.815
SC 11.798 11.290 10.837 10.383 9.930 9.386
22 TC 23.001 21.301 19.783 18.265 16.747 14.925
SC 10.609 10.126 9.695 9.264 8.833 8.316
24 TC 24.871 23.011 21.350 19.689 18.028 16.035
SC 9.419 8.962 8.553 8.145 7.736 7.246
All the data above are based on 26.7°C entering DB. To obtain data for different entering DB,
please use the formula below :
Sensible capacity (EDB) = Sensible capacity (26.7) + 1.23 x L/s x (1 - BPF) ( EDB - 26.7 ) / 1000
Where, BPF = Bypass factor
EDB = Entering dry bulb temperature, ° C
MCM020D
MLC020B
MCM025D
MLC025B
MCM030D
MLC030B
MCM030D
MLC030C
MCM040D
MLC035C
MCM040D
MLC040C
MCM050D
MLC050C
MCM061C
MLC061C
Bypass factor 0.50 0.44 0.30 0.42 0.64 0.51 0.44 0.55
Page 26
