McQuay MCM 020 D User Manual

COOLING ONLY (R407C)
MODEL : MCM020D / M4LC020B
Indoor
DB
Indoor
WB
Capacit
y Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 4.706 4.517 4.348 4.180 3.783 3.508 3.376 3.324 3.283
SC 4.627 4.454 4.300 4.147 3.753 3.481 3.349 3.298 3.257
15 TC 5.078 4.841 4.628 4.416 3.997 3.707 3.567 3.512 3.469
SC 4.446 4.290 4.151 4.012 3.631 3.368 3.240 3.191 3.151
18 TC 6.092 5.722 5.392 5.062 4.582 4.249 4.089 4.026 3.976
SC 3.952 3.842 3.743 3.644 3.298 3.059 2.943 2.898 2.863
19.4 TC 6.565 6.134 5.749 5.363 4.854 4.502 4.332 4.266 4.213
SC 3.722 3.633 3.553 3.473 3.143 2.915 2.805 2.762 2.728
20 TC 6.768 6.314 5.908 5.503 4.980 4.619 4.444 4.376 4.322
SC 3.623 3.529 3.444 3.359 3.040 2.820 2.713 2.672 2.639
22 TC 7.444 6.914 6.440 5.967 5.400 5.009 4.819 4.746 4.687
SC 3.295 3.182 3.082 2.981 2.698 2.503 2.408 2.371 2.342
24 TC 8.120 7.514 6.972 6.431 5.821 5.398 5.194 5.115 5.052
SC 2.966 2.836 2.719 2.603 2.356 2.185 2.102 2.070 2.045
HIGH AMBIENT
MODEL : MCM025D / M4LC025B
Indoor
DB
Indoor
WB
Capacit
y
Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 5.416 5.196 4.999 4.803 4.655 4.418 4.305 4.261 4.226
SC 5.053 4.909 4.781 4.652 4.509 4.280 4.170 4.128 4.094
15 TC 5.843 5.567 5.320 5.073 4.917 4.667 4.547 4.501 4.464
SC 4.684 4.590 4.507 4.424 4.288 4.070 3.965 3.925 3.893
18 TC 7.008 6.578 6.194 5.811 5.632 5.345 5.208 5.155 5.113
SC 3.678 3.722 3.761 3.801 3.683 3.496 3.406 3.372 3.345
19.4 TC 7.551 7.050 6.602 6.155 5.965 5.662 5.517 5.461 5.416
SC 3.208 3.316 3.413 3.510 3.402 3.229 3.146 3.114 3.089
20 TC 7.784 7.257 6.786 6.316 6.121 5.810 5.661 5.603 5.558
SC 3.007 3.120 3.222 3.323 3.221 3.057 2.979 2.948 2.924
22 TC 8.561 7.947 7.399 6.852 6.641 6.303 6.141 6.079 6.030
SC 2.336 2.467 2.584 2.702 2.618 2.485 2.421 2.397 2.377
24 TC 9.337 8.637 8.013 7.388 7.160 6.796 6.622 6.554 6.501
SC 1.665 1.814 1.947 2.080 2.016 1.913 1.864 1.845 1.830
HIGH AMBIENT
MODEL : MCM030D / M4LC030C
Indoor
DB
Indoor
WB
Capacit
y Outdoor DB, °C
°C °C kW 19.4 25 30 35 40 46 50 52 54
26.7 13.9 TC 7.784 7.460 7.170 6.880 6.550 6.206 5.938 5.792 5.639
SC 7.088 6.910 6.751 6.592 6.276 5.946 5.689 5.550 5.403
15 TC 8.383 7.981 7.622 7.263 6.914 6.551 6.268 6.114 5.953
SC 6.942 6.743 6.566 6.389 6.083 5.763 5.514 5.379 5.236
18 TC 10.017 9.403 8.854 8.306 7.907 7.492 7.168 6.992 6.807
SC 6.543 6.289 6.062 5.835 5.555 5.263 5.036 4.913 4.783
19.4 TC 10.779 10.066 9.429 8.792 8.371 7.931 7.588 7.402 7.206
SC 6.358 6.077 5.827 5.577 5.309 5.030 4.813 4.695 4.571
20 TC 11.106 10.357 9.688 9.019 8.587 8.136 7.784 7.593 7.392
SC 6.278 5.980 5.714 5.448 5.187 4.914 4.702 4.586 4.465
22 TC 12.195 11.326 10.551 9.775 9.307 8.817 8.437 8.230 8.012
SC 6.013 5.655 5.337 5.018 4.777 4.526 4.331 4.224 4.113
24 TC 13.284 12.296 11.414 10.531 10.026 9.499 9.089 8.866 8.632
SC 5.747 5.331 4.959 4.588 4.368 4.138 3.959 3.862 3.760
HIGH AMBIENT
Page 27
