McQuay MCM 020 D User Manual

Heat Pump (R22)
MODEL INDOOR UNIT
MCM020DR MCM025DR MCM050DR
OUTDOOR UNIT
MLC020BR MLC025BR MLC030BR MLC030CR MLC035CR MLC040CR MLC050CR
NOMINAL kcal/h
5040 6048 6552 7560 8820 10080 12096
COOLING W
5862 7034 7620 8792 10258 11723 14068
CAPACITY Btu/h
20000 24000 26000 30000 35000 40000 48000
NOMINAL kcal/h
5292 6300 7056 8064 9072 10332 12096
HEATING W
6155 7327 8206 9379 10551 12016 14068
CAPACITY Btu/h
21000 25000 28000 32000 36000 41000 48000
W (50Hz)
2216 [ 2179 ] 2993 [ 2823 ] 3114 3016 [ 3273 ] 3433 4011 [ 3912 ] [ 5115 ]
W (60Hz)
2056 2806 - 3584 - 4193 [ 5503 ]
W (50Hz)
2237 [ 2189 ] 2913 [ 2903 ] 2875 2935 [ 3129 ] 3342 3501 [ 3402 ] [ 4517 ]
W (60Hz)
2103 2740 - 3286 - 3640 [ 4337 ]
A (50Hz)
10.8 [ 4.0 ] 14.1 [ 5.2 ] 15.0 15.1 [ 5.6 ] 17.1 20.9 [ 6.7 ] [ 8.5 ]
A (60Hz)
9.6 13.1 - 17.4 - 12.1 [ 15.7 ]
A (50Hz)
10.8 [ 4.0 ] 13.8 [ 5.3 ] 14.3 14.6 [ 5.5 ] 16.5 19.0 [ 6.1 ] [ 7.9 ]
A (60Hz)
10.0 12.9 - 16.3 - 10.9 [ 13.3 ]
POWER SOURCE V/Ph/Hz
REFRIGERANT / CONTROL
AIR FLOW cfm / L/s
590 / 278 660 / 312 1110 / 524
50 Hz
4
POLES x 45
W
4
POLES x 95
W
4 POLES x 145
W
60 Hz
4
POLES x 45
W
4
POLES x 95
W
-
4
POLES x 95
W
4 POLES x 140
W
RATED INPUT POWER W (50/60Hz)
96 / 114 130 / 155 132 / - 132 / 179 240 / 337
RATED RUNNING CURRENT A (50/60Hz)
0.40 / 0.50 0.58 / 0.70 0.58 / - 0.58 / 0.80 1.04 / 1.50
MATERIAL
S.I.G.C
DIAMETER mm/in
THICKNESS mm/in
MATERIAL
THICKNESS mm/in
ROW
33 4
FIN PER INCH
12 12 12
FACE AREA
m
2
/ft
2
0.19 / 2.06 0.19 / 2.06 0.36 / 3.95
HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
WEIGHT kg
43 43 70
SOUND PRESSURE LEVEL ( H / M / L ) dBA
50 / 47 / 40 54 / 53 / 50 54 / 53 / 52
ROOM TEMPERATURE
CONTROL AIR DISCHARGE
OPERATION
CONDENSATE DRAIN SIZE mm/in
AIR FILTER
PACKING HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
V/Ph/Hz
3
80 - 420 / 3 / 5
0
V/Ph/Hz
COMPRESSOR TYPE
CAPACITOR - µF
50 Hz
45 / < NIL > 45 / < NIL > 50 45 / < NIL > 35 40 / < NIL > NIL
1∅ / < 3∅ >
60 Hz
40 60 - 45 - NIL NIL
LOCK ROTOR AMPERE - A 50 Hz
56 / < 21.4 > 57 / < 24.9 > 66 85 / < 39 > 82 100 / < 45 > 62
1∅ / < 3∅ >
60 Hz
39.6 50 - 88 - 78 106
RATED RUNNING CURR. (COOLING) -
A
50 Hz
9.84 / < 3.7 > 13.0 / < 4.8 > 13.7 13.4 / < 5.0 > 15.0 18.8 / < 6.0 > 7.8
1∅ / < 3∅ >
60 Hz
8.3 11.6 - 15.3 - 11.2 14.8
RATED RUNNING CURR. (HEATING) -
A
50 Hz
9.84 / < 3.7 > 12.7 / < 4.9 > 13.0 12.9 / < 4.9 > 14.4 16.9 / < 5.4 > 7.2
1∅ / < 3∅ >
60 Hz
8.7 11.4 - 14.2 - 10.0 12.4
RATED INPUT POWER (COOLING) - W 50 Hz
1987 / < 1950 > 2730 / < 2560 > 2816 2643 / < 2900 > 2952 3530 / < 3431 > 4634
1∅ / < 3∅ >
60 Hz
1777 2486 - 3144 - 3595 4905
RATED INPUT POWER (HEATING) - W 50 Hz
2008 / < 1960 > 2650 / < 2640 > 2577 2562 / < 2756 > 2861 3020 / < 2921 > 4036
1∅ / < 3∅ >
60 Hz
1824 2420 - 2846 - 3042 3739
PROTECTION DEVICE
POWER SOURCE V/Ph/Hz
FAN TYPE / DRIVE
BLADE MATERIAL
DIAMETER mm/in
RATED RUNNING CURRENT A (50/60Hz)
0.7 / - 1.09 / 1.25 1.09 / -
MOTOR OUTPUT W (50/60Hz)
80 / - 145 / 145 145 / -
RATED INPUT POWER W (50/60Hz)
166 / - 241 / 261 241 / -
MATERIAL
S.B.C S.I.G.C S.I.G.C S.B.C S.I.G.C. S.I.G.C S.I.G.C
DIAMETER mm/in
THICKNESS mm/in
0.35 / 0.014 0.36 / 0.014 AV
E
0.36 / 0.014 AV
E
MATERIAL
THICKNESS mm/in
ROW
2
FIN PER INCH
16
FACE AREA
m
2
/ft
2
HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
WEIGHT kg
57 58 58 95 95 100 105
MATERIAL
CASING THICKNESS mm/in
FINISHING
SOUND PRESSURE LEVEL dBA
51 52 55 58 58 58 58
TYPE
SIZE LIQUID mm/in
6.35 / 1/4
GAS mm/in
15.88 / 5/8
PACKING HEIGHT mm/in
DIMENSION WIDTH mm/in
DEPTH mm/in
NOMINAL TOTAL POWER (COOLING) - 1∅ [ 3∅ ]
NOMINAL TOTAL POWER (HEATING) - 1∅ [ 3∅ ]
240 / 337
1.04 / 1.50
9.52 / 3/8
730 / 345 1110 / 524
4 POLES x 145W
4 POLES x 140W
214 / 8.42 249 / 9.80 249 / 9.80
34
12 12
AUTOMATIC LOUVER (UP & DOWN) & MANUAL LOUVER (BOTTOM)
LCD WIRELESS / LED WIRED MICROCOMPUTER REMOTE CONTROL
19.05 / 3/4
45 70
MICROCOMPUTER CONTROLLED THERMOSTAT
PROPELLER / DIRECT
0.56 / 0.76 1.09 / 1.25
301 / 11.9 345 / 13.6 345 / 13.6
1311 / 51.6 1361 / 53.5 1816 / 71.4
22
55 / 55 145 / 145
850 / 33.46
840 / 33.10 1029 / 40.53
16
0.51 / 5.53 0.87 / 9.33
51 / 50 / 48 54 / 53 / 52
WASHABLE SARAN NET (OPTIONAL IONIZER FILTER)
710 / 27.95 1000 / 39.37
GALVANISED MILD STEEL
0.8 / 0.031
9.52 / 3/8 9.52 / 3/8
646 / 25.40
MCM030DR MCM040DR
0.36 / 3.95
670 / 26.30 670 / 26.30
1214 / 47.80 1214 / 47.80 1714 / 67.40
670 / 26.30
0.24 / 2.58
NOMINAL TOTAL CURRENT (COOLING) - 1∅ [ 3∅ ]
NOMINAL TOTAL CURRENT (HEATING) - 1∅ [ 3∅ ]
INDOOR UNIT
220 - 240 / 1 / 50, 208 - 230 / 1 / 60
2
/ CAPILLARY TUBE IN OUTD
O
R22 / CAPILLARY TUBE & TXV IN OUTDOOR
FAN
FAN MOTOR
4 POLES x 95W
COI L
TUBE
S.B.C. S.I.G.C S.B.C.
0.35 / 0.014
FI N
ALUMINIUM ALUMINIUM (HYDROPHILIC)
0.11 / 0.0043
760 / 29.9 760 / 29.9 760 / 29.9
OUTDOOR UNI T
COMPRESSOR
POWER SOURCE
220 - 240 / 1 / 50 / < 380 - 420 / 3 / 50 >
208 - 230 / 1 / 60 200 - 230 / 3 / 60
ROTARY HERMETIC RECIPROCATING HERMETIC
OVERLOAD PROTECTION
R
LOAD PROTECTION AND AUTO RESET HIGH PRESSURE S
W
FAN
GLASS REINFORCED ACRYL STYRENE RESIN
420.0 / 16.5 609.6 / 24.0
133 / 165 241 / 261
220 - 240 / 1 / 50, 208 - 230 / 1 / 60
COI L
TUBE
9.52 / 3/8
0.36 / 0.014 AVE. 0.35 / 0.014
FI N
ALUMINIUM (SLIT FIN TYPE) ALUMINIUM (CORRUGATED FIN TYPE)
0.127 / 0.005
14
PI PE
FLARE VALVE
15.88 / 5/8 19.05 / 3/4
461 / 18.15 560 / 22.05
330 / 13.00 400 / 15.75
POLYESTER POWDER
957 / 37.68 1200 / 47.24
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
b) HEATING - 21.1°C DB / 15.6°C WB INDOOR AND 8.3°C DB / 6.1°C WB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
b) HEATING - 21.0°C DB INDOOR AND -8.3°C DB / -9.4°C WB OUTDOOR TO
26.7°C DB INDOOR AND 23.9°C DB / 18.3°C WB
Page 4
