McQuay MCM 020 D User Manual

Cooling Only (R22)
MODEL INDOOR UNIT
MCM061C
OUTDOOR UNIT
MLC061C
NOMINAL kcal/h
14110
COOLING W
16410
CAPACITY Btu/h
56000
NOMINAL TOTAL POWER W
5593
NOMINAL TOTAL CURRENT A
9.4
POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50
REFRIGERANT / CONTROL
R22 / CAPILLARY TUBE IN INDOOR
AIR FLOW cfm / L/s
1550 / 732
HIGH
56
MED
53
LOW
46
FAN MOTOR
2 x 4 POLES x 80 W
RATED INPUT POWER W
327
RATED RUNNING CURRENT A
1.40
MATERIAL
S.I.G.C
DIAMETER mm/in
9.52 / 3/8
THICKNESS mm/in
0.35 / 0.014
MATERIAL
ALUMINIUM
THICKNESS mm/in
0.11 / 0.0043
ROW
4
FIN PER INCH
14
FACE AREA
m
2
/ft
2
0.42 / 4.51
HEIGHT mm/in 285 / 11.2
DIMENSION WIDTH mm/in
1874 / 73.8
DEPTH mm/in
666 / 26.2
WEIGHT kg
85
CONTROL ROOM TEMPERATURE
MICROCOMPUTER CONTROLLED THERMOSTAT
OPERATION
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSATE DRAIN SIZE mm/in
19.05 / 3/4
AIR FILTER
WASHABLE SARAN NET
PACKING HEIGHT mm/in
368 / 14.5
DIMENSION WIDTH mm/in
1992 / 78.4
DEPTH mm/in
760 / 29.9
POWER SOURCE V/Ph/Hz
415 / 3 / 50
COMPRESSOR TYPE
SCROLL
CAPACITOR µF
-
LOCK ROTOR AMP. A
74.0
RATED RUNNING CURRENT A
8.5
RATED INPUT POWER W
5008
PROTECTION DEVICE OVERLOAD PROTECTION / HI-LO PRESSURE SWITCH
POWER SOURCE V/Ph/Hz
220 - 240 / 1 / 50
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL
GLASS R. ACRLY STYLENE RESIN
DIAMETER mm/in
600 / 24
RATED RUNNING CURRENT A
1.2
MOTOR OUTPUT W
400
RATED INPUT POWER W
258
MATERIAL
S.I.G.C
DIAMETER mm/in
9.52 / 3/8
THICKNESS mm/in
0.35 / 0.014
MATERIAL
ALUMINIUM (SLIT)
THICKNESS mm/in
0.127 / 0.005
ROW
3
FIN PER INCH
14
FACE AREA
m
2
/ft
2
0.84 / 9.04
HEIGHT mm/in
850 / 33.5
DIMENSION WIDTH mm/in 1030 / 40.6
DEPTH mm/in
460 / 18.1
WEIGHT kg
108
MATERIAL
ELECTRO GALVANIZED MILD STEEL
CASING THICKNESS mm/in
1.0 - 2.3 (0.0393 -0.0905)
FINISHING
EPOXY POLYESTER POWDER COATING
SOUND PRESSURE LEVEL dBA
61
TYPE
FLARE VALVE
SIZE LIQUID mm/in
12.7 / 1/2
GAS mm/in
19.05 / 3/4
PACKING HEIGHT mm/in
1016 / 40.0
DIMENSION WIDTH mm/in
1178 / 46.4
DEPTH mm/in
602 / 23.7
INDOOR UNIT
FAN
SOUND LEVEL (dBA)
COIL
TUBEFINTUBEFIN
PIPE
OUTDOOR UNIT
COMPRESSORFANCOIL
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING CAPACITY IS BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
Abbreviation
S.B.C.
S.I.G.C
Page 5

McQuay MCM 020 D Specifications

General

Brand	McQuay
Model	MCM 020 D
Category	Air Conditioner
Language	English
