Cooling Only (R22)
MODEL INDOOR UNIT MCM062C
OUTDOOR UNIT MLC061C
NOMINAL kcal/h 14110
COOLING W 16410
CAPACITY Btu/h 56000
NOMINAL TOTAL POWER W 6195
NOMINAL TOTAL CURRENT A
30.6
POWER SOURCE V/Ph/Hz 230 / 1 / 60
REFRIGERANT / CONTROL R22 / CAPILLARY TUBE IN INDOOR
AIR FLOW cfm / L/s
1550 / 732
HIGH 56
MED 53
LOW
46
FAN MOTOR 2 x 4 POLES x 80 W
RATED INPUT POWER W 338
RATED RUNNING CURRENT A 1.60
MATERIAL S.I.G.C
DIAMETER mm/in 9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL
ALUMINIUM
THICKNESS mm/in 0.11 / 0.0043
ROW 4
FIN PER INCH
14
FACE AREA
m
2
ft
2
0.42 / 4.51
HEIGHT mm/in 285 / 11.2
DIMENSION WIDTH mm/in 1903 / 74.9
DEPTH mm/in 680 / 26.8
WEIGHT kg 85
CONTROL ROOM TEMPERATURE MICROCOMPUTER CONTROLLED THERMOSTAT
OPERATION
LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSATE DRAIN SIZE mm/in 19.05 / 3/4
AIR FILTER WASHABLE SARAN NET
PACKING HEIGHT mm/in
368 / 14.5
DIMENSION WIDTH mm/in 1984 / 78.1
DEPTH mm/in 760 / 29.9
POWER SOURCE V/Ph/Hz 230 / 1 / 60
COMPRESSOR TYPE SCROLL
CAPACITOR µF 70
LOCK ROTOR AMP. A 144.0
RATED RUNNING CURRENT A
27.7
RATED INPUT POWER W 5500
PROTECTION DEVICE OVERLOAD PROTECTION / HI-LO PRESSURE SWITCH
POWER SOURCE V/Ph/Hz
230 / 1 / 60
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL GLASS R. ACRLY STYLENE RESIN
DIAMETER mm/in 600 / 24
RATED RUNNING CURRENT A
1.7
MOTOR OUTPUT W 160
RATED INPUT POWER W 357
MATERIAL S.I.G.C
DIAMETER mm/in 9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL ALUMINIUM (SLIT)
THICKNESS mm/in
0.127 / 0.005
ROW 3
FIN PER INCH 14
FACE AREA
m
2
ft
2
0.84 / 9.04
HEIGHT mm/in 850 / 33.5
DIMENSION WIDTH mm/in 1030 / 40.6
DEPTH mm/in
460 / 18.1
WEIGHT kg 108
MATERIAL ELECTRO GALVANIZED MILD STEEL
CASING THICKNESS mm/in 1.0 - 2.3 (0.0393 -0.0905)
FINISHING EPOXY POLYESTER POWDER COATING
SOUND PRESSURE LEVEL dBA 61
TYPE FLARE VALVE
SIZE LIQUID mm/in
12.7 / 1/2
GAS mm/in 19.05 / 3/4
PACKING HEIGHT mm/in 1016 / 40.0
DIMENSION WIDTH mm/in
1178 / 46.4
DEPTH mm/in 602 / 23.7
INDOOR UNIT
FAN
SOUND LEVEL (dBA)
COIL
TUBEFINTUBEFIN
PIPE
OUTDOOR UNIT
COMPRESSORFANCOIL
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING AND HEATING CAPACITY ARE BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
Abbreviation
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
Page 6
