McQuay MCM 020 D User Manual

Heat Pump (R22)
MODEL INDOOR UNIT MCM061CR
OUTDOOR UNIT MLC061CR
NOMINAL kcal/h 14110
COOLING W
16410
CAPACITY Btu/h 56000
NOMINAL kcal/h 14110
HEATING W 16410
CAPACITY Btu/h
56000
NOMINAL TOTAL POWER (COOLING) W 5593
NOMINAL TOTAL POWER (HEATING) W 4551
NOMINAL TOTAL CURRENT (COOLING) A 9.4
NOMINAL TOTAL CURRENT (HEATING) A
8.1
POWER SOURCE V/Ph/Hz
220 - 240 / 1 / 50
REFRIGERANT / CONTROL R22 / CAPILLARY TUBE - INDOOR (COOLING), OUTDOOR (HEATING)
AIR FLOW cfm / L/s 1550 / 732
HIGH
56
MED
53
LOW 46
FAN MOTOR 2 x 4 POLES x 80 W
RATED INPUT POWER W 327
RATED RUNNING CURRENT A
1.40
MATERIAL S.I.G.C
DIAMETER mm/in 9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL
ALUMINIUM
THICKNESS mm/in 0.11 / 0.0043
ROW 4
FIN PER INCH 14
FACE AREA
m
2
/
ft
2
0.42 / 4.51
HEIGHT mm/in 285 / 11.2
DIMENSION WIDTH mm/in 1874 / 73.8
DEPTH mm/in 666 / 26.2
WEIGHT kg
85
CONTROL ROOM TEMPERATURE MICROCOMPUTER CONTROLLED THERMOSTAT
OPERATION LCD WIRELESS OR WIRED MICROCOMPUTER REMOTE CONTROL
CONDENSATE DRAIN SIZE mm/in 19.05 / 3/4
AIR FILTER
WASHABLE SARAN NET
PACKING HEIGHT mm/in
368 / 14.5
DIMENSION WIDTH mm/in 1992 / 78.4
DEPTH mm/in 760 / 29.9
POWER SOURCE V/Ph/Hz 415 / 3 / 50
COMPRESSOR TYPE
SCROLL
CAPACITOR µF -
LOCK ROTOR AMP. A 74.0
RATED RUNNING CURRENT (COOLING) A 8.5
RATED RUNNING CURRENT (HEATING) A
7.2
RATED INPUT POWER (COOLING) W 5008
RATED INPUT POWER (HEATING) W 3966
PROTECTION DEVICE OVERLOAD PROTECTION / HI PRESSURE SWITCH
POWER SOURCE V/Ph/Hz
220 - 240 / 1 / 50
FAN TYPE / DRIVE
PROPELLER / DIRECT
BLADE MATERIAL
GLASS R. ACRLY STYLENE RESIN
DIAMETER mm/in 600 / 24
RATED RUNNING CURRENT A 1.2
MOTOR OUTPUT W 400
RATED INPUT POWER W
258
MATERIAL S.I.G.C
DIAMETER mm/in 9.52 / 3/8
THICKNESS mm/in 0.35 / 0.014
MATERIAL
ALUMINIUM (CORRUGATED)
THICKNESS mm/in
0.127 / 0.005
ROW 3
FIN PER INCH 14
FACE AREA
m
2
/
ft
2
0.84 / 9.04
HEIGHT mm/in
850 / 33.5
DIMENSION WIDTH mm/in 1030 / 40.6
DEPTH mm/in 460 / 18.1
WEIGHT kg 108
MATERIAL
ELECTRO GALVANIZED MILD STEEL
CASING THICKNESS mm/in 1.0 - 2.3 (0.0393 -0.0905)
FINISHING EPOXY POLYESTER POWDER COATING
SOUND PRESSURE LEVEL dBA 61
TYPE
FLARE VALVE
SIZE LIQUID mm/in 12.7 / 1/2
GAS mm/in 19.05 / 3/4
PACKING HEIGHT mm/in 1016 / 40.0
DIMENSION WIDTH mm/in
1178 / 46.4
DEPTH mm/in 602 / 23.7
INDOOR UNIT
FAN
SOUND LEVEL (dBA)
COIL
TUBEFINTUBEFIN
PIPE
OUTDOOR UNIT
COMPRESSORFANCOIL
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ARI 210/240-94
3) NOMINAL COOLING CAPACITY IS BASED ON THE CONDITIONS BELOW :
a) COOLING - 26.7°C DB / 19.4°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
Abbreviation
S.B.C.
S.I.G.C
Page 7
