Model : MLC/ M4LC030/ 040/ 050/ 061 C/CR, M4LC060C
MLC035 C/CR
NO PART DESCRIPTION NO. PART DESCRIPTION
1 BASE PAN 11 MOTOR BRACKET ASSY
2 FLARE VALVE 12 SIDE PANEL LEFT
3 FLARE VALVE 13 FAN MOTOR
4 PARTITION 14 FAN BLADE
5 COMPRESSOR 15 FRONT PANEL ASSY
6 ACCESS PANEL 16 TERMINAL BOX ASSY
7 ACCUMULATOR 17 PLATE, FLARE VALVE
8 BACK PANEL
9 TOP PANEL
10 COIL ASSY
Page 92
