Performance Tables
R22 50Hz
COOLING CAPACITY
MODEL : MDB075D vs. MMC075D
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
22.504 21.052 19.756 18.459 17.163 15.607 14.569 14.051 13.532
13.9
SC
22.504 21.052 19.756 18.459 17.163 15.607 14.569 14.051 13.532
TC
23.139 21.712 20.438 19.163 17.889 16.360 15.340 14.831 14.321
15.0
SC
21.639 20.340 19.180 18.020 16.861 15.469 14.541 14.077 13.613
TC
24.872 23.512 22.299 21.085 19.871 18.414 17.443 16.958 16.472
18.0
SC
19.280 18.399 17.611 16.824 16.037 15.093 14.463 14.148 13.833
TC
25.680 24.353 23.167 21.981 20.796 19.373 18.424 17.950 17.476
19.4
SC
18.179 17.493 16.879 16.266 15.653 14.917 14.426 14.181 13.936
TC
26.027 24.684 23.485 22.285 21.086 19.647 18.688 18.208 17.728
20.0
SC
17.708 17.012 16.392 15.771 15.150 14.406 13.909 13.661 13.413
TC
27.182 25.788 24.544 23.299 22.055 20.561 19.566 19.068 18.570
22.0
SC
16.135 15.412 14.766 14.121 13.475 12.701 12.184 11.926 11.668
TC
28.337 26.893 25.603 24.313 23.023 21.476 20.444 19.928 19.412
26.7
24.0
SC
14.562 13.811 13.141 12.471 11.800 10.996 10.460 10.191 9.923
MODEL : MDB100D vs. MMC100D
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
28.053 26.528 25.166 23.805 22.443 20.809 19.720 19.175 18.630
13.9
SC
28.053 26.528 25.166 23.805 22.443 20.809 19.720 19.175 18.630
TC
29.485 27.841 26.373 24.905 23.438 21.676 20.502 19.915 19.328
15.0
SC
27.084 25.734 24.528 23.323 22.117 20.671 19.706 19.224 18.742
TC
33.389 31.421 29.664 27.907 26.151 24.042 22.637 21.934 21.232
18.0
SC
24.441 23.568 22.788 22.008 21.229 20.293 19.670 19.358 19.046
TC
35.210 33.092 31.200 29.308 27.417 25.147 23.633 22.876 22.120
19.4
SC
23.207 22.557 21.976 21.395 20.814 20.117 19.653 19.420 19.188
TC
35.991 33.804 31.851 29.898 27.945 25.601 24.039 23.258 22.477
20.0
SC
22.679 21.984 21.364 20.744 20.124 19.380 18.884 18.636 18.388
TC
38.594 36.178 34.021 31.864 29.706 27.118 25.392 24.529 23.666
22.0
SC
20.916 20.075 19.324 18.573 17.823 16.921 16.321 16.020 15.720
TC
41.197 38.552 36.190 33.829 31.468 28.634 26.745 25.801 24.856
26.7
24.0
SC
19.154 18.167 17.285 16.403 15.521 14.463 13.758 13.405 13.052
MODEL : MDB125D vs. MMC125D
Outdoor DB, °CIndoor DB
°C
Indoor WB
°C
Capacity
kW
19.4 25.0 30.0 35.0 40.0 46.0 50.0 52.0 54.0
TC
36.030 33.921 32.037 30.154 28.271 26.011 24.505 23.751 22.998
13.9
SC
36.030 33.921 32.037 30.154 28.271 26.011 24.505 23.751 22.998
TC
38.503 35.972 33.711 31.450 29.190 26.477 24.669 23.764 22.860
15.0
SC
35.263 33.211 31.378 29.545 27.713 25.514 24.047 23.314 22.581
TC
45.250 41.565 38.275 34.986 31.696 27.748 25.116 23.800 22.484
18.0
SC
33.173 31.275 29.580 27.885 26.190 24.156 22.801 22.123 21.445
TC
48.398 44.176 40.406 36.635 32.865 28.341 25.325 23.817 22.309
19.4
SC
32.197 30.371 28.741 27.110 25.480 23.523 22.219 21.567 20.914
TC
49.747 45.445 41.604 37.763 33.922 29.313 26.240 24.704 23.167
20.0
SC
31.779 29.898 28.219 26.540 24.860 22.845 21.502 20.830 20.158
TC
54.245 49.678 45.601 41.523 37.446 32.553 29.291 27.660 26.029
22.0
SC
30.386 28.323 26.480 24.638 22.796 20.586 19.112 18.375 17.639
TC
58.743 53.911 49.597 45.283 40.969 35.793 32.342 30.616 28.891
26.7
24.0
SC
28.992 26.747 24.742 22.737 20.732 18.326 16.723 15.921 15.119
