page 6
2.7 MDS Unit
MDS 060 A R- F AA
Heat pump, omitted if cooling only unit
Po
wer supply features: A: 220V~/50Hz
F: 380V/3N~/50Hz
Description of the products
Design serial No.
Cooling capacity No.
McQuay MDS unit
MEX Throttle Box Nomenclature:
MEX 14 2-- -SA A
Connecting pipe size
Connecting pipe mode
Design serial No.
Valve opening size No.
Unit name No.
Unit name no. MEX: McQuay throttle box (one expansion valve)
Valve opening size no. 14: Nominal diameter value (mm)*10
Connecting pipe size 2: 1/4 inch
3: 3/8 inch
4: 1/2 inch
Connecting pipe mode SA: Flare fitting & nipple joint
Design serial no. A: Primary design
2.5 Electric Heater Box
HD 1.2
T
08-15
Heating capacity (kW)
Applicable units: T means the unit can be used in MCC "T"
series
8-15 means it can be used in MCC008/010/015T
18-30 means it can be used in MCC018/020/025/030T
40 means it can be used in MCC040T
40-50 means it can be used in MCC040/050T
60 means it can be used in MCC060T
P
Heating unit: P means the heating unit is PTC
Omitted means the heating unit is electric heating pipe
Electric heater box
2.6 Hot Water Heater Box
HW
T
08-15
Hot water heater box
Applicable units: T means the unit can be used in MCC "T"
series
08-15 means it can be used in MCC008/010/015T
18-30 means it can be used in MCC018/020/025/030T
40-50 means it can be used in MCC040/050T
60 means it can be used in MCC060T
