3 Technical Parameter
MDS030A(R)~MDS060A(R)
Model MDS030A MDS030AR MDS040A MDS040AR MDS050A MDS050AR MDS060A MDS060AR
Cooling(kW) 8.5 8.5 10.0 10.0 12.5 12.5 14.5 14.5
Heating(kW) - 9.0 - 11.5 - 13.5 - 16.5
Power 220V~/50Hz
Noise dB(A) 59 59 59 60
W×D×H(mm) 840×408×900 1058×430×1044 1058×430×1044 1058×430×1247
Weight(kg)
82 85 112 115 117 120 123 130
Power consumption in cooling(kW)
3.0 3.0 3.5 3.6 4.4 4.4 5.0 5.0
Ampere in cooling(A) 13.6 13.6 15.9 15.9 20 20 22.8 22.8
Power consumption in cooling(kW)
- 2.5 - 3.4 - 4.2 - 4.2
Ampere in cooling(A) - 11.4 - 13.5 - 19 - 20.3
Refrigerant
R22
Connecting
Gas Flare fitting and nipple joint connecting
Liquid Flare fitting and nipple joint connecting
LiquidΦ(mm(in)) 9.52(3/8) 9.52(3/8) 9.52(3/8) 9.52(3/8)
GasΦ(mm(in)) 15.88(5/8) 19.05(3/4) 19.05(3/4) 19.05(3/4)
Model MDS050A MDS050AR MDS060A MDS060AR
Cooling(kW) 12.5 12.5 15 15
Heating(kW) - 13.5 - 17
Power
380V/3N~/50Hz
Noise dB(A) 59 60
W×D×H(mm) 1058×430×1044 1058×430×1247
Weight(kg)
117 120 123 130
Power consumption in cooling(kW)
4.4 4.4 5.0 5.0
Ampere in cooling(A) 8.4 8.4 9.6 9.6
Power consumption in cooling(kW) - 4.2 - 4.23
Ampere in cooling(A) - 8.0 - 8.8
Refrigerant
R22
Connecting
Gas Flare fitting and nipple joint connecting
Liquid Flare fitting and nipple joint connecting
LiquidΦ(mm(in)) 9.52(3/8)
GasΦ(mm(in)) 19.05(3/4)
MDS080B(R)~MDS300B(R)
Model MDS080B MDS080BR MDS100B MDS100BR MDS120B MDS120BR MDS150B MDS150BR
Cooling(kW) 24.5 24.5 28.0 28.0 32.5 32.5 40.0 40.0
Heating(kW) - 26.0 - 30.0 - 34.0 - 43.0
Power 380V/3N~/50Hz
Noise dB(A) 62 64 66 67
W×D×H(mm) 990×840×1840 1290×840×1840
Weight(kg)
275 290 285 300 290 305 355 370
Power consumption in cooling(kW)
7.5 7.5 8.5 8.5 9.8 9.8 12.9 12.9
Ampere in cooling (A) 14.6 14.6 16.8 16.8 18.8 18.8 23.1 23.1
Power consumption in cooling(kW)
- 7.2 - 8.3 - 9.0 - 11.1
Ampere in cooling (A) - 13.6 - 15.7 - 16.7 - 22.6
Refrigerant
R22
Connecting
Gas Welding flange
Liquid Expanded copper tube
LiquidΦ(mm(in)) 12.7(1/2) 15.88(5/8)
GasΦ(mm(in)) 28.6(1 1/8) 34.9(1 3/8)
Max. indoors-quantity
13 16 16 20
