page 8
Model MDS180B MDS180BR MDS200B MDS200BR MDS220B MDS220BR MDS240B MDS240BR
Cooling(kW) 47.5 47.5 50.0 50.0 55.0 55.0 65.0 65.0
Heating(kW) - 50.0 - 53.0 - 58.0 - 68.0
Power
380V/3N~/50Hz
Noise dB(A) 66 66 66 68
W×D×H(mm) 1990×840×1840
Weight (kg)
520 550 560 590 560 590 570 600
Power consumption in cooling(kW)
14.1 14.1 15.2 15.2 16.7 16.7 19.8 19.8
Ampere in cooling (A) 28.2 28.2 31.1 31.1 32.7 32.7 38.5 38.5
Power consumption in cooling(kW) - 13.2 - 14.7 - 16.2 - 18.5
Ampere in cooling(A) - 27.1 - 29.4 - 31.0 - 33.8
Refrigerant
R22
Connecting
Gas Welding flange
Liquid Expanded copper tube
LiquidΦ(mm(in)) 15.88(5/8) 19.05(3/4)
GasΦ(mm(in)) 34.9(1 3/8) 38.1(1 1/2)
Max. indoors-quantity
24 24 24 24
Model MDS260B MDS260BR MDS280B MDS280BR MDS300B MDS300BR
Cooling(kW) 70.0 70.0 75.0 75.0 80.0 80.0
Heating(kW) - 75.0 - 80.0 - 85.0
Power 380V/3N~/50Hz
Noise dB(A) 68 69 69
W×D×H(mm) 2280×840×1840 2580×840×1840
Weight(kg)
645 675 710 740 710 740
Power consumption in cooling(kW)
21.3 21.3 22.8 22.8 26.2 26.2
Ampere in cooling(A) 40.0 40.0 42.5 42.5 46.5 46.5
Power consumption in cooling(kW)
- 20.9 - 22.0 - 23.6
Ampere in cooling(A) - 37.2 - 41.0 - 43.1
Refrigerant
R22
Connecting
Gas Welding flange
Liquid Expanded copper tube
LiquidΦ(mm(in)) 19.05(3/4)
GasΦ(mm(in)) 41.3(1 5/8)
Max. indoors-quantity
32 32 32
Notes:
1. Cooling condition: Indoor D/W bulb Temp. 27/19ºC, outdoor temperature: D/W bulb Temp. 35/24ºC.
2. Heating condition: Indoor D/W bulb Temp. 20/15ºC, outdoor temperature: D/W bulb Temp. 7/6ºC.
Ceiling Concealed Indoor Units
Model MCC008T MCC010T MCC015T MCC018T MCC020T
Cooling capacity(W) 2000 2500 3650 4500 5600
Heating capacity(W) 2200 2600 3700 4700 6100
Power
220V~/50Hz
Noise dB(A) 31 34 35
W×D×H(mm) 1030×469×220 1290×490×250
Weight(kg)
22 25
Power input(W) 47 81 82
Fan number
2
Air flow(H: m
³/h) 450 580 800
ESP(Pa)
15(0/30/50)
Drain
Φ(mm(in)) 19.05(3/4)
Protection Anti-freezing
Connection
Gas Expanded copper tube
Liquid Expanded copper tube
LiquidΦ(mm(in)) 6.35(1/4) 9.52(3/8)
GasΦ(mm(in)) 9.52(3/8) 12.7(1/2) 15.88(5/8)
