page 9
Model MCC025T MCC030T MCC040T MCC050T MCC060T
Cooling capacity(W) 6500 7800 10600 12400 14400
Heating capacity(W) 7400 8900 11600 14500 17300
Power
220V~/50Hz
Noise dB(A) 37 42 47 48
W×D×H(mm) 1290×490×250 1640×490×250 1900×490×250
Weight(kg)
27 28 39 45
Power input(W)
123 158 276 280
Fan number
2 3 4
Air flow(H : m
³/h) 960 1200 1900 2100
ESP(Pa)
15(0/30/50) 30(15/50/70) 50(15/30/70)
Drain
Φ(mm(in)) 19.05(3/4
”
)
Protection Anti-freezing
Connection
Gas Expanded copper tube
Liquid Expanded copper tube
LiquidΦ(mm(in)) 9.52(3/8
”
)
GasΦ(mm(in)) 15.88(5/8
”
) 19.05(3/4
”
)
Notes:
1. Cooling condition: Indoor D/W bulb Temp. 27/19ºC, outdoor temperature: D/W bulb Temp. 35/24ºC.
2. Heating condition: Indoor D/W bulb Temp. 20/15ºC, outdoor temperature: D/W bulb Temp. 7/6ºC.
Ceiling Duct Indoor Unit
Model MDB050T MDB060T
Cooling capacity(W) 12500 14000
Heating capacity(W) 14000 15500
Power
220V~/50Hz
Noise dB(A) 58 60
W×D×H(mm) 1230×910×350 1430×910×350
Weight(kg)
69 75
Power consumption(W)
615 790
Fan number
1
Air flow(H m
³/h) 2250 3000
ESP(Pa)
100
Drain
Φ(mm(in)) 19.05(3/4)
Protection Anti-freezing, overload
Connection
Gas Expanded copper tube
Liquid Expanded copper tube
LiquidΦ(mm(in)) 9.52(3/8)
GasΦ(mm(in)) 19.05(3/4)
Notes:
1. Cooling condition: Indoor D/W bulb Temp. 27/19ºC, outdoor temperature: D/W bulb Temp. 35/24ºC.
2. Heating condition: Indoor D/W bulb Temp. 20/15ºC, outdoor temperature: D/W bulb Temp. 7/6ºC.
Vertical Floor Standing & Horizontal Ceiling Mounted Indoor Unit
Model MCM020T MCM030T MCM050T
Cooling capacity(W) 5800 7500 12500
Heating capacity(W) 5800 8000 13500
Power
220V~/50Hz
Noise dB(A) 48 50 52
W×D×H(mm) 1214×670×214 1214×670×249 1714×670×249
Weight(kg)
39 44 44
Power consumption(W)
81 116 161
Number of fan
2 3 4
Air flow(H m
³/h) 1100 1300 1850
Drain
Φ(mm(in)) 20.5(4/5)
Protection Anti-freezing, overheat
Connection
Gas Expanded copper tube
Liquid Expanded copper tube
LiquidΦ(mm(in)) 9.52(3/8) 9.52(3/8)
GasΦ(mm(in)) 15.88(5/8) 19.05(3/4)
Notes:
1. Cooling condition: Indoor D/W bulb Temp. 27/19ºC, outdoor temperature: D/W bulb Temp. 35/24ºC.
2. Heating condition: Indoor D/W bulb Temp. 20/15ºC, outdoor temperature: D/W bulb Temp. 7/6ºC.

McQuay MDS030A Specifications
