Appendix A: Dimension
MDS080,100,120,150,180,200,220,240,260,280,300,320 B(R) Unit: mm
Model A B Model A B Model C D
MDS080/100/120B(R)/
120B(R)M
900 990
MDS150B(R)/130B(R)S/
150B(R)M/150B(R)S/
160B(R)M/160B(R)S
1200 1290
MDS180/200/220/
240B(R)
950 1990
AMDS260/280/300B/320(R)are combined units, made up by a master unit and a slave unit
Combined unit MDS260B(R) MDS280B(R) MDS300B(R) MDS320B(R)
Master unit +
Slave unit
MDS120B(R)M+
MDS150B(R)S
MDS150B(R)M+
MDS130B(R)S
MDS150B(R)M+
MDS150B(R)S
MDS160B(R)M+
MDS160B(R)S
D 990+10+1290 1290+10+1290 1290+10+1290 1290+10+1290
MCC008,010,015,018,020,025,030,040,050,060T Unit: mm
MODEL A B C D E F G H I J FAN AMOUNT
MCC008/010/015T 690 722 1054
751 39 210 469 118 9 220 2
MCC018/020/025/030T
950 981 1314
1005 32 248 490 81 14 251 2
MCC040/050T 1300 1331 1664
1355 32 248 490 81 14 251 3
MCC060T 1560 1591 1924
1615 32 248 490 81 14 251 4


D
Detail M
Screw Hole 14  20
Detail M
8-14x20 Screw
hole (for setting)
14-14x20
Screw hole
