6
CEILING CONCEALED – VERTICAL CONDENSING UNIT (COOLING ONLY)
1) ALL SPECIFICATIONS ARE SUBJECTED TO CHANGE BY THE MANUFACTURER WITHOUT PRIOR NOTICE.
2) ALL UNITS ARE BEING TESTED AND COMPLY TO ISO
3) NOMINAL COOLING CAPACITY IS BASED ON THE CONDITIONS BELOW :
a) COOLING - 27.0°C DB / 19.0°C WB INDOOR AND 35°C DB OUTDOOR
4) ALLOWABLE OPERATING RANGE
a) COOLING - 19.4°C DB / 13.9°C WB INDOOR AND 19.4°C DB OUTDOOR TO
26.7°C DB / 19.4°C WB INDOOR AND 46.1°C DB OUTDOOR
5) THE UNIT WILL OPERATE SATISFACTORILY UP TO AN OUTSIDE TEMPERATURE OF 51.7 °C WITHOUT TRIPPING OR OVERHEATING.
Abbreviation
S.B.C. - SEAMLESS BARE COPPER
S.I.G.C - SEAMLESS INNER GROOVE COPPER
MODEL INDOOR UNIT MCC 025C MCC 030C MCC 050C MCC 060C
OUTDOOR UNIT MVCU 025A MVCU 030A MVCU 035A MVCU 040A MVCU 050A MVCU 060A
NOMINAL kcal/h 6048 7813 9073 10080 12348 14364
COOLING W
7034 9086 10551 11723 14360 16705
CAPACITY Btu/h
24000 31000 36000 40000 49000 57000
EFFECTIVE TOTAL POWER W 2494 3070 3570 3400 4460 5160
NOMINAL TOTAL POWER W 2540 3179 3685 3515 4624 5376
NOMINAL TOTAL CURRENT A 12.8 5.5 6.3 6.3 8.7 9.1
POWER SOURCE V/Ph/Hz
REFRIGERANT / CONTROL R22 / OUTDOOR CAP. TUBE
AIR FLOW cfm / L/s 730 / 345 900 / 429 1590 / 750 1650 / 779
STATIC PRESSURE mm Aq 521 1818
FAN MOTOR
4 POLES x 100W 4 POLES x 320W 4 POLES x 400W 4 POLES x 400W 4 POLES x 480W 4 POLES x 600W
RATED INPUT POWER W
180 421 550 448 510 562
RATED RUNNING CURRENT A 0.77 1.90 2.60 1.98 2.26 2.47
MATERIAL
DIAMETER mm/in
THICKNESS mm/in
MATERIAL
THICKNESS mm/in 0.11/ 0.0043
ROW
FIN PER INCH
FACE AREA
m
2
/ft
2
0.203 / 2.187 0.27 / 2.98 0.40 / 4.40 0.47 / 5.16
HEIGHT mm/in 261 / 10.3
DIMENSION WIDTH mm/in 1200 / 47.2 929 / 36.6 1299 / 51.1 1499 / 59.0
DEPTH mm/in 411 / 16.2
WEIGHT kg 25 39 54 62
SOUND PRESSURE LEVEL ( SH* / H / M / L ) dBA 40 / 39 / 36 49* / 46 / 42 / 38 53* / 52 / 50 / 47 55* / 53 / 50 / 47
CONTROL ROOM TEMPERATURE
OPERATION
CONDENSATE DRAIN SIZE mm/in
AIR FILTER
PACKING HEIGHT mm/in 410 / 16.1
DIMENSION WIDTH mm/in 1386 / 54.6 1110 / 43.7 1481 / 58.3 1685 / 66.3
DEPTH mm/in 535 / 21.1
POWER SOURCE V/Ph/Hz 230 / 1 / 50
COMPRESSOR TYPE ROTARY
CAPACITOR
µF
50 NIL NIL NIL NIL NIL
LOCK ROTOR AMP. A
70 40 46 48 66 74
RATED RUNNING CURRENT A
11.5 4.8 5.3 5.2 7.5 7.9
RATED INPUT POWER W
2223 2618 2860 2819 3829 4529
PROTECTION DEVICE
POWER SOURCE V/Ph/Hz
FAN TYPE / DRIVE
BLADE MATERIAL
DIAMETER mm/in
RATED RUNNING CURRENT A 0.69 0.62 1.20 1.14 1.28 1.28
RATED INPUT POWER W
137 140 275 248 285 285
MATERIAL
DIAMETER mm/in
THICKNESS mm/in
MATERIAL
THICKNESS mm/in
ROW
FIN PER INCH 18 20
FACE AREA
m
2
/ft
2
1.72 / 18.59
HEIGHT mm/in
984 / 38.7
DIMENSION WIDTH mm/in
762 / 30.0
DEPTH mm/in
762 / 30.0
WEIGHT kg 64 70 70 93 100 102
SOUND PRESSURE LEVEL dBA 57 59 62
MATERIAL
CASING THICKNESS mm/in
FINISHING
TYPE
INDOOR LIQUID mm/in
12.70 / 1/2
GAS mm/in
19.05 / 3/4 19.05 / 3/4
OUTDOOR LIQUID mm/in
12.70 / 1/2
GAS mm/in 19.05 / 3/4 22.23 / 7/8
PACKING HEIGHT mm/in 1090 / 42.9
DIMENSION WIDTH mm/in 860 / 33.9
DEPTH mm/in 860 / 33.9
MCC 040C
INDOOR UNIT
220-240 / 1 / 50
R22 / CAPILLARY TUBE IN INDOOR
FAN
1100 / 517
21
COIL
TUBE
S.B.C.
9.52 / 3/8
0.35 / 0.014
FIN
ALUMINIUM
0.127 / 0.005
33
12 14
0.31 / 3.44
378 / 14.9
1045 / 41.1
541 / 21.3
42
51* / 49 / 45 / 41
MICROCOMPUTER CONTROLLED THERMOSTAT
SLM WIRED HANDSET (OPTIONAL AC5300 REMOTE CONTROLLER)
19.05 / 3/4
WASHABLE SARAN NET
399 / 15.7
1229 / 48.4
615 / 24.2
OUTDOOR UNIT
COMPRESSOR
400 / 3 / 50
SCROLL
INTERNAL OVERLOAD PROTECTION
FAN
230 / 1 / 50
PROPELLER / DIRECT
METAL
450 / 18 600 / 24
COIL
TUBE
S.I.G.C
9.52 / 3/8
0.35 / 0.014
FIN
ALUMINIUM (SLIT FIN TYPE)
0.11 / 0.0043
1
1.09 / 11.76 1.93 / 20.78
22
841 / 33.1 1086 / 42.8
572 / 22.5 762 / 30.0
572 / 22.5 762 / 30.0
GALVANISED MILD STEEL
1.2 / 0.047
POLYESTER POWDER
PIPE
BRAZED VALVE
SIZE
9.52 / 3/8 9.52 / 3/8
15.88 / 5/8 19.05 / 3/4
9.52 / 3/8 9.52 / 3/8
15.88 / 5/8 19.05 / 3/4
950 / 37.4 1190 / 46.9
660 / 26.0 860 / 33.9
660 / 26.0 860 / 33.9
