Outlines & Dimensions
72
Model: MCK20/25/30/40/50AW
DETAIL A
SEE DETAIL A
WATER OUTLET
WATER INLET
820
820
63
363
335
28
158
113
930
642
555
555
930
622
Note: Dimension in mm
