2-1
English
Français
Unité Intérieure [Série (5)WMJ]
CONTOUR ET DIMENSIONS
A
B
VUE DE DEVANT
VUE DE DESSUS
C
VUE LATÉRALE
H
I
B
LA MARQUE INDIQUE LA DIRECTION DES TUYAUX
ARRIÈRE ARRIÈRE
DROITE
GAUCHE
BAS BAS
VIS FIXES DE LA GRILLE AVANT
(INTÉRIEUR)
VOLET
RÉCEPTEUR DE SIGNAL
UNITÉ INTÉRIEURE
INTERRUPTEUR DE
MARCHE/ARRÊT
THERMISTOR DE TEMPÉRATURE
DE LA PIÈCE (INTÉRIEUR)
PLAQUE
D’IDENTIFICATION
RÉPARTITEUR
AVEC BORNE
DE MISE À LA
TERRE
Points de fixation de la plaque
de montage recommandés
(5 points en tout)
Utilisez un mètre à
ruban comme indiqué,
placez l’extrémité du
mètre à ruban
sur
F
E
J
G
G
L
D
B
K
M
A
Extrémité du
tuyau de gaz
PLAQUE D’INSTALLATION (5)WM09/10/15J/JR
Extrémité du tuyau de liquide
Trou percé dans
le mur à Ø 65mm
Toutes les dimensions sont données en mm/(pouces)
Position du tuyau
d’évacuation
F
Traduction des
instructions d’origine
2 IM-WMJ-1207(2)_FR 11/20/09, 4:32 PM1
