3-3
Deutsch
Abmessung A B C D E F G H I J K L M N O
20C/CR 855 628 328 508 181 44 93 149 101 113 603 126 164 17 49
(33,7) (24,7) (12,9) (20,0) (7,1) (1,7) (3,7) (5,9) (4,0) (4,4) (23,7) (5,0) (6,4) (0,7) (1,9)
25C/CR 855 730 328 513 182 44 93 149 101 113 603 126 164 17 47
(33,7) (28,7) (12,9) (20,2) (7,2) (1,7) (3,7) (5,9) (4,0) (4,4) (23,7) (5,0) (6,4) (0,7) (1,9)
Abmessung P Q R S T
20C/CR 32 3 23 73 75
(1,3) (0,1) (0,9) (2,9) (3,0)
25C/CR 32 3 23 73 75
(1,3) (0,1) (0,9) (2,9) (3,0)
B
A
Q
R
ST
DO
KLL
CN
P
M
N
FE
C
GH
IJ
NUR FÜR
SL25C/CR
Alle Dimensionen sind in mm/(zoll)
Außen-Gerät [SL Serien]
3 IM-WMJ-1207(2)_DE 11/20/09, 4:33 PM3
