McQuay SWT C Series User Manual

14 IM709
Table 3. Compressor circuit charge
* Charge quantities listed are averages. Actual charge quantity is dependent
on individual unit evaporator coil circuiting. Actual charge quantities are
stamped on each unit nameplate.
Table 4. Compressor application chart
COMPRESSOR
(HP)
*REFRIGERANT
CHARGE PER
CIRCUIT (R-22)
OIL CHARGE
PER CIRCUIT
(OZ.)
69 Ibs.53
10 14 lbs. 132
13 18 lbs. 128
SWT
MODEL
SIZE
COMPRESSOR HORSEPOWER MIN.
GPM
(L/s)
MAX
GPM
(L/s)
CKT#1
CKT#2
CKT#3
CKT#4
018C
6 6 - - 24 (1.5) 42 (2.7)
6 6 6 - 36 (2.3) 62 (4.0)
6 6 6 6 48 (3.0) 84 (5.3)
023C
6 6 6 - 35 (2.2) 65 (4.1)
6 6 6 6 48 (3.0) 84 (5.3)
6 6 6 6 58 (3.7) 102 (6.4)
6 6 6 10 58 (3.7) 102 (6.4)
6 6 10 10 68 (4.3) 119 (7.5)
028C
6 6 6 6 48 (3.0) 84 (5.3)
6 6 6 10 58 (3.7) 102 (6.4)
6 6 10 10 68 (4.3) 119 (7.5)
6 10 10 10 78 (4.9) 137 (8.7)
035C
6 6 6 10 58 (3.7) 102 (6.4)
6 6 10 10 68 (4.3) 119 (7.5)
6 10 10 10 78 (4.9) 137 (8.7)
10 10 10 10 88 (5.6) 154 (9.7)
040C
6 6 6 10 58 (3.7) 102 (6.4)
6 6 10 10 68 (4.3) 119 (7.5)
6 10 10 10 78 (4.9) 137 (8.7)
10 10 10 10 88 (5.6) 154 (9.7)
10 10 13 13 104 (6.5)
183
(11.5)
13 13 13 13 120 (7.6)
212
(13.4)
