McQuay SWT C Series User Manual

18 IM709
Unit Weights
Table 6a. Unit and Component Weight
English Units in lbs.
(1) Water economizer weight includes valves and piping.
(2) Hot water coil weight includes valve piping
Table 6b. Unit and Component Weight
SI Units in kg.
(1) Water economizer weight includes valves and piping.
(2) Hot water coil weight includes valve piping
COMPONENT
UNIT SIZE
018C 023C 028C 035C 040C
MAIN COOLING/HEATING SECTION
Main Base 946 946 946 1045 1045
4 Row DX Coil 206 238 278 333 354
6 Row DX Coil 250 294 347 417 450
Comp./Cond. Water
(2) 6 hp 26 560 — — — —
(3) 6 hp 35 705 705 — — —
(4) 6 hp 43 856 856 856 856 —
(3) 6, (1) 10 hp 57 — 987 987 987 987
(2) 6, (2) 10 hp 66 — 1105 1105 1105 1105
(1) 6, (3) l0 hp 74 — — 1233 1233 1233
(4) 10 hp 95 — — — 1368 1368
(2) 10, (2) 13 hp — — — — — 1511
(4) 13 hp — — — — — 1654
Hot Water Coil,
1 Row, 12 fpi
(2)
71 97 119 130 152
HW Coil Water Weight 16 20 23 28 32
Electric Heat -34 kW 20 20 20 20 20
Skid for Main 99 99 99 115 115
FILTER/WATERSIDE ECONOMIZER SECTION
Base 368 368 428 428
Water Economizer Coil
4 Row
(1)
266 298 340 393 410
Economizer Water Weight 51 65 75 94 111
FAN SECTION
Fan & Frame 900 930 930 1120 1120
Skid for Fan Section 98 98 98 115 115
Supply Fan Motors
3 hp Open Dripproof 71 — — — —
5 hp Open Dripproof 82 — — — —
7 1/2 hp Open Dripproof 124 124 — — —
l0 hp Open Dripproof 144 144 144 144 —
l5 hp Open Dripproof — 185 185 185 185
20 hp Open Dripproof — — 214 214 214
25 hp Open Dripproof — — — — 266
3 hp Totally Enclosed 72 — — — —
5 hp Totally Enclosed 85 — — — —
71/2
hp Totally Enclosed
140 140 — — —
10 hp Totally Enclosed 170 170 170 170 —
15 hp Totally Enclosed — 235 235 235 235
20 hp Totally Enclosed — — 300 300 300
25 hp Totally Enclosed — — — — 330
COMPONENT
UNIT SIZE
018C 023C 028C 035C 040C
MAIN COOLING/HEATING SECTION
Main Base 429 429 429 474 474
4 Row DX Coil 94 108 126 151 161
6 Row DX Coil 113 133 157 189 204
Comp./Cond. Water
(2) 6 hp 12 254 — — — —
(3) 6 hp 16 320 320 — — —
(4) 6 hp 20 388 388 388 388 —
(3) 6, (1) 10 hp 26 — 448 448 448 448
(2) 6, (2) 10 hp 30 — 501 501 501 501
(1) 6, (3) l0 hp 34 — — 559 559 559
(4) 10 hp 43 — — — 621 621
(2) 10, (2) 13 hp — — — — — 680
(4) 13 hp — — — — — 744
Hot Water Coil,
1 Row, 12 fpi
(2)
32 44 54 59 69
HW Coil Water Weight 7 9 10 13 15
Electric Heat -34 kW 9 9 9 9 9
Skid for Main 45 45 45 52 52
FILTER/WATERSIDE ECONOMIZER SECTION
Base 167 167 167 194 194
Water Economizer Coil
4 Row
(1)
121 135 154 178 186
Economizer Water Weight 23 29 34 43 50
FAN SECTION
Fan & Frame 408 422 422 508 508
Skid for Fan Section 44 44 44 52 52
Supply Fan Motors
3 hp Open Dripproof 32 — — — —
5 hp Open Dripproof 37 — — — —
7 1/2 hp Open Dripproof 56 56 — — —
l0 hp Open Dripproof 65 65 65 65 —
l5 hp Open Dripproof — 84 84 84 84
20 hp Open Dripproof — — 97 97 97
25 hp Open Dripproof — — — — 121
3 hp Totally Enclosed 32 — — — —
5 hp Totally Enclosed 39 — — — —
71/2
hp Totally Enclosed
64 64 — — —
10 hp Totally Enclosed 77 77 77 77 —
15 hp Totally Enclosed — 107 107 107 107
20 hp Totally Enclosed — — 136 136 136
25 hp Totally Enclosed — — — — 150
