McQuay SWT040C User Manual

16 IM709
Figure 15. Unit Front Plan and Front Elevation
Notes:
1. Service connections determined when facing the front of
the unit. Left hand standard, right hand optional. Please indi-
cate on the unit submittal.
2. Unit sizes 018C, 023C and 028C have a single fan.
3. Unit sizes 018C, 023C and 028C have a single mechanical
access panel in bottom front and bottom back.
F FDD
15.0
(381)
E
6.46
(164)
34.0
(864)
78.5
(199.4)
B
72.0
(182.8)
Mechanical
Access
Power entry
7/8" (2.2) KO
Electrical
Access
MicroTech II
System
Indicator
Panel
Fan
Outlets
1.0 (25)Neoprene
Isolation Pads
shipped separately
Connection
Plate
Return Air
Unit Front Plan
Left side piping
connections
Right side piping
connections
(optional)
Supply fan motor
Front Elevation
(For dimentions B, D, E and F see Table 5)
ASD
(Optional)
