McQuay WSC 100 User Manual

IM 1128-2 35
Type II
The following tables give the dimensions and weights of the various components as shipped.
Table 2, Type II Dimensions & Weights
Unit
Size
Vessel Code
Cond.
Width
Cond.
Height
Front &
Back
Support
Width
Front &
Back
Support
Height
Evaporator
Width
Evaporator
Height
Compressor
Width
Compressor
Height
063
E2009 / C1809
31.8
(806.5)
36.8
(933.5)
8.0 (203.2)
22.9
(580.9)
34.6
(877.8)
28.8
(731.3)
44.0
(1118.6)
25.1
(638.3)
063
E2209 / C2009
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.9
(580.9)
34.6
(877.8)
35.4
(899.9)
44.0
(1118.6)
25.1
(638.3)
063
E2209 / C2209
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.1
(561.8)
34.6
(877.8)
35.4
(899.9)
44.0
(1118.6)
25.1
(638.3)
063
E2609 / C2209
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.1
(561.8)
39.2
(996.7)
35.9
(912.6)
44.0
(1118.6)
25.1
(638.3)
063
E2609 / C2609
36.0
(914.9)
42.3
(1073.2)
8.0 (203.2)
27.7
(704.6)
39.2
(996.7)
35.9
(912.6)
44.0
(1118.6)
25.1
(638.3)
063
E3009 / C2609
36.0
(914.9)
42.3
(1073.2)
8.0 (203.2)
27.0
(685.5)
42.6
(1081.0)
37.3
(948.4)
44.0
(1118.6)
25.1
(638.3)
063
E2012 / C1812
31.8
(806.5)
36.8
(933.5)
8.0 (203.2)
22.9
(580.9)
34.6
(877.8)
28.8
(731.3)
44.0
(1118.6)
25.1
(638.3)
063
E2212 / C2012
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.9
(580.9)
34.6
(877.8)
35.4
(899.9)
44.0
(1118.6)
25.1
(638.3)
063
E2212 / C2212
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.1
(561.8)
34.6
(877.8)
35.4
(899.9)
44.0
(1118.6)
25.1
(638.3)
063
E2612 / C2212
30.5
(774.2)
36.8
(933.5)
8.0 (203.2)
22.1
(561.8)
39.2
(996.7)
35.9
(912.6)
44.0
(1118.6)
25.1
(638.3)
063
E2612 / C2612
36.0
(914.9)
42.3
(1073.2)
8.0 (203.2)
27.7
(704.6)
39.2
(996.7)
35.9
(912.6)
44.0
(1118.6)
25.1
(638.3)
063
E3012 / C2612
36.0
(914.9)
42.3
(1073.2)
8.0 (203.2)
27.0
(685.5)
42.6
(1081.0)
37.3
(948.4)
44.0
(1118.6)
25.1
(638.3)
079
E2209 / C2209
30.5
(775.2)
33.1
(841.0)
8.0 (203.2)
20.6
(522.0)
32.8
(834.1)
31.5
(799.8)
43.6
(1108.2)
25.1
(638.3)
079
E2609 / C2209
30.5
(775.2)
35.9
(911.4)
8.0 (203.2)
20.6
(522.0)
36.7
(933.2)
33.2
(842.3)
43.6
(1108.2)
25.1
(638.3)
079
E2609 / C2609
30.5
(775.2)
39.3
(997.0)
8.0 (203.2)
26.2
(665.0)
36.7
(933.2)
33.2
(842.3)
43.6
(1108.2)
25.1
(638.3)
079
E3009 / C2609
36.0
(914.9)
39.3
(997.0)
8.0 (203.2)
25.4
(645.2)
40.1
(1017.8)
37.3
(948.4)
43.6
(1108.2)
25.1
(638.3)
079
E3009 / C3009
41.4
(1052.3)
45.8
(1162.1)
8.0 (203.2)
30.9
(783.8)
42.6
(1081.0)
37.3
(948.4)
43.6
(1108.2)
25.1
(638.3)
079
E3609 / C3009
41.9
(1063.5)
45.8
(1162.1)
8.0 (203.2)
25.5
(648.7)
48.1
(1222.2)
43.7
(1109.7)
43.6
(1108.2)
25.1
(638.3)
079
E2212 / C2212
30.5
(775.2)
33.1
(841.0)
8.0 (203.2)
20.6
(522.0)
32.8
(834.1)
31.5
(799.8)
43.6
(1108.2)
25.1
(638.3)
079
E2612 / C2212
30.5
(775.2)
35.9
(911.4)
8.0 (203.2)
20.6
(522.0)
36.7
(933.2)
33.2
(842.3)
43.6
(1108.2)
25.1
(638.3)
079
E2612 / C2612
30.5
(775.2)
39.3
(997.0)
8.0 (203.2)
26.2
(665.0)
36.7
(933.2)
33.2
(842.3)
43.6
(1108.2)
25.1
(638.3)
079
E3012 / C2612
36.0
(914.9)
39.3
(997.0)
8.0 (203.2)
25.4
(645.2)
40.1
(1017.8)
37.3
(948.4)
43.6
(1108.2)
25.1
(638.3)
079
E3012 / C3012
41.4
(1052.3)
45.8
(1162.1)
8.0 (203.2)
30.9
(783.8)
42.6
(1081.0)
37.3
(948.4)
43.6
(1108.2)
25.1
(638.3)
079
E3612 / C3012
41.9
(1063.5)
45.8
(1162.1)
8.0 (203.2)
25.5
(648.7)
48.1
(1222.2)
43.7
(1109.7)
43.6
(1108.2)
25.1
(638.3)
Table continued on next page.
