7. Board Functions
Programming
There are two functions which can be adjusted in programming mode.
The default settings should be good for your marker.
 Motor Speed– 3 levels of adjustment, level (1) being the slowest motor speed and level (3) being
the fastest.
Note: It is recommended that you do not set the speed higher than needed. Using higher speeds
than needed will only shorten the life of your batteries.
 Sound Sensitivity– 3 levels of adjustment, level (1) being the least sensitive and level (3) being
the most sensitive. This setting is only used in sound activation mode.
Preloading the Drive Carrier Spring
If you remove the drive carrier for cleaning it will be necessary to preload the drive carrier spring.
Follow the instructions below.
If any paintballs break inside the box drive; do not use any liquids or chemicals to rinse out the box
drive; doing so will cause severe damage to the box drive electronics.
 Install the spring cup, drive spring, and drive carrier onto the drive shaft. Make sure the spring
sits in the spring cup correctly.
 Rotate the drive carrier clockwise until its tab hits the spring housing tab. You should now have
both spring tabs pressed together.
 Lift the drive cone slightly and rotate it clockwise up and over the spring cup’s tab, taking the
upper spring tab with it.
 Snap the drive carrier down with the drive spring tab on the right side of the drive cup’s tab.
 The drive cone spring is now pre-loaded and will snap back properly when wound up.
