page 16
* All of the parts and hardware you will need are
supplied with the crib at the time of purchase.
Unscrew the Allen head bolts and
remove the front panel assembly.
Move the spring frame to the lowest level.
Attach the guardrail (L) to the front posts using
four Allen head bolts (H22) and lock washer
(H23). The guardrail (L) can be installed with
the high end facing either to the left or the
right.
Check to make sure that all of the bolts are
fastened securely.
DO NOT OVERTIGHTEN.
STEP 1.
STEP 2.
STEP 3.
H22
H22
H23
H23
L. Guardrail
H22
H23
H22H23
L
L
Crib + Changer Combo (5591)-Toddler Bed Conversion Assembly
The mattress intended for use on the bed shall be a full-size crib mattress having
minimum dimensions of 51-5/8 in. (1310mm) in length, 27-1/4 in. (690mm) in width
and 4 in. (100mm) in thickness, or a greater thickness not exceeding 6 in (152mm).
The intended user’s minimum age must be at
least 15 months old and maximum weight must not exceed 50 lbs (22.7 kg).
WARNING :
Failure to follow these warnings and the assembly instructions could result in
serious injury or death from entrapment or strangulation.
DO NOT place bed near windows where cords from blinds or drapes may strangle a child. DO NOT place
items with a string, cord, or ribbon, around a child’s neck, such as hood strings or pacifier cords. DO NOT
suspend strings over a toddler bed for any reason. If guard rails are used as the mattress containment
means, guard rails provided must be used to avoid the formation of a gap between the mattress and the bed
that could cause an entrapment.
