MDB 5591 - Hardware

page 3
HARDWARE
Tools Needed
(not included)
Phillips
screwdriver
H1. 3 -1/2” Allen Head Bolt (8) H2. 2 -3/4” Allen Head Bolt (2)
H3. 2 -1/2” Allen Head Bolt (16) H4. 1 -3/4” Allen Head Bolt (8)
H5. 1” Allen
Head Bolt (4)
H6. Barrel
Nut (24)
H13. 1/2” Small Wood
Screw for Glides (36)
H14. 1-1/8” Bolt
for Knob (3)
H15. Knob (3)
H16. Right Panel Glide (3)
H17. Right Drawer Glide (3)
H18. Left Panel Glide (3)
H19. Left Drawer Glide (3)
H24. Allen
Wrench
GUARDRAIL HARDWARE
H22. 2” Allen Head Bolt (4) H23. Lock washer (4)
T. Dresser Front
Top Bar
S. Dresser Back
Panel
Z. Dresser
Top Board
U. Dresser Center
Bar (2)
X. Dresser Bottom
Bar (2)
W. Dresser Top
Bar
V. Dresser Middle
Bar (2)
H20. Strap
H21. Wood
Screw (2)
BB. Pad
H7. 1-1/4” Wood
Screw (24) H9. 1” Metal Pin (20)
Y. Dresser
Center Board
H25. Lock
washer (38)
H26. Washer (4) H27. 7/8" Wood
Screw (2)
AA-2. Dresser
Shelf (with pre-drilled
screw holes)
AA-1. Dresser
Shelf
