page 9
STEP 10. Attach spring frame
Swing out four hangers at corner of the spring frame (K) carefully. Attach spring frame FLAT SIDE UP.
Choose the height of the spring frame. Start at the highest level and adjust accordingly.
Bolt the spring frame (K) to legs using Allen head bolts (H5), washers (H26), lock washers (H25) and Allen
wrench (H24). As the child grows, it is important to lower the spring.
Make sure the spring frame is level.
Do not overtighten.
Make sure the mattress support frame is installed FLAT SIDE UP. Make sure the mattress
support frame is level when installing.
*As your child grows, it is important to lower the mattress support.
K. Spring Frame
H26
K
H25
H5
To Next Page
