MDS 78 FS Pro Ring User Manual

1 8
Dimensions (mm) A B C D E F G H I
.18 FS Pro 25 32 11 35 63.5 77 10/32 28 3
.28 FS Pro 29 38 15 47 75 92
1
/
4
x 28 35 3
.38 FS Pro 31 38 15 47 77 92
1
/
4
x 28 35 3
.40 FS-1 36 44 17.5 51 87 110
1
/
4
x 28 37 3
.48 FS Pro 36 44 17.5 51 87 115
1
/
4
x 28 37 3
.58 FS Pro 36 44 17.5 55 94 115
1
/
4
x 28 42 3
.68 FS Pro 40 52 25 55 100 120
5
/
16
x 24 42 4
.78 FS Pro Ring 40 52 25 55 100 120
5
/
16
x 24 42 4
1.48 FS Pro Ring 48 58 30 60 122 148
5
/
16
x 24 40 4
N/A= data unavailable at this time
MDS instruction manual 5x6.5 4/28/00 3:11 PM Page 18

MDS 78 FS Pro Ring Specifications

General

Brand	MDS
Model	78 FS Pro Ring
Category	Engine
Language	English
