26
For UK plug
If the plug on this appliance is
damaged, it can be replaced
with a BS 1363 plug, fitted
with a 3A BS 1362 fuse.
Only use a 3 amp fuse with
this appliance. Care must
be taken when changing the
plug. If in doubt, contact a qualified electrician.
Specifications
Light spectrum
550 – 1200 nm
Max elo
-
s energy 9J/cm2
Max Optical 4J/cm
2
Conducted RF 5J/cm
2
(in equivalent optical units)
Pulsed light repetition rate
Up to 2 pulses/second (2 Hz)
RF Wave frequency
6.78 MHz
Radiofrequency power
5 Watts
Coverage rate
Up to 6 cm
2
/second
Electrical power input
200-240 VAC, 50 Hz
Dimensions and weight
20.5 x 15 x 9 cm [W x L x H)
1.17 Kg
Acceptable Environmental Conditions
Storage and transportation
Temperature -10ºC to 55ºC
Humidity 90% at 55ºC (137ºF)
Pressure 700-1060hPa
Operation:
Temperature 10ºC to 30ºC
Relative Humidity up to 80% at 37ºC
Altitude up to 3900 m (13,000 ft)
NB: The system will not operate above 30ºC.
If device was stored in high humidity, let it dry for
an hour before usage
EN
