applicator components (Figure 2):
6. light output window.
7. RF chrome contact bars (Both RF chrome bars must be in complete contact with
the skin for the light pulses to ash).
8. cartridge: comes attached to the applicator and is preloaded with pulses.
You will need to replace the cartridge when the Empty indicator light on the base
unit is red. *
9. activation button.
10. cooling outlet.
11. accessory protective cap (not to be removed).
*If you don’t have a replacement cartridge – make sure you place the
protective cap instead of the used cartridge. This is in order to protect the inner parts
of applicator.
Applicator Bottom View
Applicator Top View
8
7
10
9
6
11
Figure 2: Top and bottom view of applicator with cartridge
system
