Page 48 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1
43831 Left Rear Black Wheel 1
43028 Left Rear Non-Marking Wheel 1
2 42015 Drive Hub 1
3 50040 Screw HHCS M12-1.75 × 35 2
4 53148 WSHR M12 Spring Washer 2
5 50003 WSHR M12 Standard Flat Washer 2
6 50285 Nut NNYL M04 × 0.70 8
7 50284 WSHR M04 Standard Flat Washer 8
8 43030 Switch Plate 2
9 53113 Screw SHCS M04-0.70 × 16 4
10 43031 Limit Switch 2
11 53115 Screw SHCS M04-0.70 × 25 4
12 43032 Adjusting Plate 1
13 43033 Bumper 1
14 50004 WSHR M16 Standard Flat Washer 6
15 53149 WSHR M16 Spring Washer 6
16 50479 Screw HHCS 5/8-11 × 1 3/4 6
17 53474 Screw HHCS 7/16-14 × 1 1/2 2
18 43034 Washer 2
19 REF Rear Motor Assembly (Refer to page 51) 1
20 43035 Rear Motor Housing Weldment 1
21 43036 Cover 1
22 53481 No-Slip Clip-On Barrel Nut M06-1.00 2
23 50028 Screw HHCS M06-1.00 × 20 2
24 53046 WSHR M06 Spring Washer 2
25 50000 WSHR M06 Standard Flat Washer 2
26 53477 Nut NHEX 5/8-18 UNF 9
REF - Reference
