Page 58 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1
43442 Beacon 1
43060 Beacon (Revolving Light) (With Beacon Cover 43061) 1
2 53124 Screw SHCS M06-1.00 × 20 3
3 50000 WSHR M06 Standard Flat Washer 21
4 50047 Nut NNYL M06-1.00 15
5 50033 Screw HHCS M10-1.50 × 25 4
6 53054 WSHR M10 Spring Washer 4
7 53375 WSHR M10 Flat Fender Washer 8
8 -- -- --
9 -- -- --
10 -- -- --
11 -- -- --
12 REF Function Manifold Assembly (Refer to page 61) 1
13 53478 WSHR M12 Flat Fender Washer 4
14 53148 WSHR M12 Spring Washer 4
15 50039 Screw HHCS M12-1.75 × 30 4
16 43047 Hydraulic Tray Weldment 1
17 50218 WSHR M08 Flat Fender Washer 4
18 50048 Nut NNYL M08 × 1.25 4
19 -- -- --
20 -- -- --
21 -- -- --
22 REF Ground Control Box Assembly (Refer to page 63) 1
23 41112 Hydraulic Hoses Manifolds (4069RT) 1
24 50386 Screw CSCS M06-1.00 × 25 (4069RT) 2
25 43066 Hose (4069RT) (To Hydraulic Tank) 1
26 43067 Hose (4069RT) (To Upper Lift Cylinder) 1
27 43068 Hose (4069RT) (To Lower Lift Cylinder) 1
28 53231 Screw PHMS M06-1.00 × 16 6
29 43069 Hinge 1
30 43070 Rubber Pad 1
31 REF Hydraulic Tank Assembly (Refer to
page 65) 1
32 43071 Tank Strap 1
33 50034 Screw HHCS M10-1.50 × 30 4
34 50002 WSHR M10 Standard Flat Washer 8
35 50049 Nut NNYL M10 × 1.50 4
36 REF Drive Manifold Assembly (Refer to page 59) 1
37 43072 Rubber Pad 1
38 43073 Tank Strap 1
39 REF Fuel Tank Assembly (Refer to page 67) 1
40 43074 Oil Cooler 1
REF - Reference
To Next Page
