Page 60 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 REF Drive Manifold (Refer to page 151) 1
2 43080 Straight Fitting 6
3 43083 Straight Fitting 8
4 53375 WSHR M10 Flat Fender Washer 4
5 53054 WSHR M10 Spring Washer 4
6 50033 Screw HHCS M10-1.50 × 25 4
7 43126 Drive Manifold Bracket 1
8 50030 Screw HHCS M08-1.25 × 20 3
9 53055 WSHR M08 Spring Washer 3
10 50001 WSHR M08 Standard Flat Washer 3
11 43082 Elbow 1
12 43127 Outrigger Manifold 1
13 43076 Straight Fitting 2
REF - Reference
