Page 66 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 41413 Nut 1
2 41167 Fitting 1
3 44002 Washer 2
4 41166 Fitting 1
5 42055 Air Cleaner 1
6 50359 Screw SHCS M05-0.80 × 16 8
7 53043 WSHR M05 Spring Washer 10
8 50028 Screw HHCS M06-1.00 × 20 20
9 53046 WSHR M06 Spring Washer 20
10 50000 WSHR M06 Standard Flat Washer 20
11 53038 WSHR M05 Standard Flat Washer 6
12 53081 Screw HHCS M05-0.80 × 12 2
13 46648 Keeper Bar 1
14 43109 Tank Cover 1
15 43110 Filter Web 1
16 43130 Level Gauge 1
17 43112 Elbow 2
18 43085 Straight Fitting 3
19 43113 Return Filter 1
-- 42837 Filter Element 1
20 43114 Pipe 1
21 43115 Tee Fitting 1
22 43116 Straight Fitting 1
23 43117 Tee Fitting 1
24 43118 Straight Fitting 1
25 43119 Plug 1
26 43120 Plug 1
27 43121 Flange 1
28 43122 O-Ring 1
29 43123 Suction Filter 1
30 43124 Plug 1
31 46700 Hydraulic Tank Weldment 1
33 43108
Rubber Pad 1
34 43107 Cover Weldment 1
