Page 74 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 43136 Air Cleaner Cap 1
2 43137 Clamp 1
3 43138 Air Cleaner Cap Mounting Weldment 1
4 50033 Screw HHCS M10-1.50 × 25 5
5 50002 WSHR M10 Standard Flat Washer 13
6 50049 Nut NNYL M10 × 1.50 10
7
43442 Beacon 1
43060 Beacon (Revolving Light) (With Beacon Cover 43061) 1
8 53124 Screw SHCS M06-1.00 × 20 3
9 50000 WSHR M06 Standard Flat Washer 19
10 50047 Nut NNYL M06-1.00 19
11 43139 Switch Protection Plate 1
12 53038 WSHR M05 Standard Flat Washer 18
13 50524 Nut NNYL M05 × 0.80 8
14 53351 Screw PHMS M05-0.80 × 16 4
15 42071 Power Switch 1
16 53378 Screw PHMS M05-0.80 × 12 2
17 53043 WSHR M05 Spring Washer 2
18 53479 Screw PHMS M05-0.80 × 20 4
19 43131 Engine Tray Weldment 1
20 41064 Half-Round Batten 2
21 50028 Screw HHCS M06-1.00 × 20 13
22 REF Radiator Shroud Assembly (Refer to page 75) 1
23 50068 WSHR M06 Flat Fender Washer 10
24 53014 Nut NHEX M08-1.25 4
25 53055 WSHR M08 Spring Washer 4
26 50001 WSHR M08 Standard Flat Washer 4
27 43142 Battery Keeper Bar 1
28 43143 Threaded Rod 2
29 43144 Battery 1
30 53054 WSHR M10 Spring Washer 3
31 41049 Bumper 1
32
53375 WSHR M10 Flat Fender Washer 6
33 43146 Bumper Bracket 1
34 43147 Spacer 1
35 50127 Screw SHCS M10-1.50 × 30 2
36 53225 Screw CSCS M10-1.50 × 30 2
37 43148 Washer 1
38 50051 Nut NNYL M16 × 2.00 1
39 REF Engine System Assembly (Refer to page 77, page 81, and page 83) 1
40 43149 Bearing 2
41 50430 Screw HHCS M10-1.50 × 45 4
42 43150 Engine Pivot Mounting Weldment 1
43 43151 Pin 1
44 41431 Pin 1
REF - Reference
