Page 80 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 43159 Cover 1
2 50033 Screw HHCS M10-1.50 × 25 6
3 53054 WSHR M10 Spring Washer 6
4 50002 WSHR M10 Standard Flat Washer 6
5 43161 Clamp 2
6 43160 Hose 1
7 43162 Cooler 1
8 43163 Cover 1
9 53150 Screw SHCS M05-0.80 × 20 2
10 53038 WSHR M05 Standard Flat Washer 2
11 43164 Bottle Fixing Plate 1
12 46702 Coolant Recovery Bottle 1
13 43166 Bottle Bracket 1
14 50031 Screw HHCS M08-1.25 × 25 2
15 50001 WSHR M08 Standard Flat Washer 4
16 50048 Nut NNYL M08 × 1.25 2
17 50524 Nut NNYL M05 × 0.80 2
18 50021 Screw HHCS M10-1.50 × 55 2
19 53375 WSHR M10 Flat Fender Washer 4
20 43168 Cooler Bracket 1
21 43167 Bumper 6
22 50049 Nut NNYL M10 × 1.50 1
23 43169 Support 1
24 43170 Bracket Weldment 1
25 50022 Screw HHCS M10-1.50 × 70 1
To Next Page
