Page 82 XX69RT Series - Service & Parts Manual
November 2022Section 8 - Chassis
Item Part Number Description Qty.
1 -- Air Cleaner Cap Mounting Weldment (Refer to page 73) 1
2 43137 Clamp 4
3 43171 Hose 1
4 43172 Hose 1
5 43173 Air Cleaner Bracket 1
6 53317 WSHR 3/8 Standard Flat Narrow Washer 1
7 53316 WSHR 3/8 Spring Washer 1
8 53376 Screw HHCS 3/8-16 × 1 3/8 1
9 50000 WSHR M06 Standard Flat Washer 4
10 53046 WSHR M06 Spring Washer 4
11 50028 Screw HHCS M06-1.00 × 20 4
12 43174 Mu󰀪er Bracket 1
13 53361 Nut NHEX M06-1.00 4
14 43175 Mu󰀪er 1
15 53375 WSHR M10 Flat Fender Washer 4
16 53054 WSHR M10 Spring Washer 4
17 50033 Screw HHCS M10-1.50 × 25 4
18 50001 WSHR M08 Standard Flat Washer 6
19 53055 WSHR M08 Spring Washer 4
20 50032 Screw HHCS M08-1.25 × 30 4
21 50048 Nut NNYL M08 × 1.25 2
22 50030 Screw HHCS M08-1.25 × 20 1
23 50218 WSHR M08 Flat Fender Washer 2
24 50282 Screw HHCS M08-1.25 × 35 2
25 43176 Air Cleaner 1
-- 43177 Filter Element (Outer) 1
-- 46703 Filter Element (Inner) 1
