Plug in servos and
LED module into ports
1, 2 and 3.
Right Arm Servo
Left Arm Servo
Neck Servo
Left Foot Motor
Right Foot Motor
Plug in
left foot motor
and right foot motor.
Plug in battery cable.
Plug in speaker.
Make sure robot is in
robot mode.
Turn robot on.
Well done, your
build is complete.
2.1 CONNECT THE ELECTRONICS
146
