MechMaxx GS650 - To-Scale Hardware

TO-SCALE HARDWARE
TO-SCALE HARDWARE
10
www. mechmaxx.com
Hardware graphics are printed at 1:1 scale for ease of identification. Simply place the hardware over the image in the
tables to verify it is the correct size.
M8 X 30mm
Hex bolt
4X
M10 X 25mm
Hex bolt
4X
M10 X 80mm
Hex bolt
9X
10
Flat washer
14X
8
Flat washer
4X
14
Flat washer
2X
8
Spring washer
4X
15X
nut M10
Hex lock
2X
nut M14
Hex lock
