The display will show:
RESET - When the load limit is reached, the output signal
triggers the relay and the RESET key must be pressed to clear
the line before starting the next test.
CONTINUOUS - The relay will be activated every time the
load limit is reached and the output signal will remain on.
PULSE - The relay will be activated momentarily when the
load limit is reached.
Select the desired function and press the ENTER key.
The display will show SET and a default load limit at which
output signal will trigger the relay. To set the required load
limit use UP and DOWN keys to adjust the value and the
ENTER key to confirm the selection.
The display will show:
ST
ATE
HIGH - Will set PLC signal at AFG’s high alarm setting
LOW - Will set PLC signal at AFG’s low alarm setting
Select the desired function and press the ENTER key.
The display will revert back to PLC sub-menu 1 and PLC ON
will now be displayed.
Press ESC key to return to main-menu page 1.
The AFG may be used to send a signal to control the
Mecmesin range of motorised test stands via a dedicated
cable.
To configure the signal output from the AFG, press and hold
the MENU key until page 1 of the main-menu appears. Press
the DOWN key to move the arrow cursor to STAND and
press the ENTER key.
AT LIMITS sub-menu 1
AT LIMITS sub-menu 2
AT ALARM sub-menu 1
STAND
Contact your supplier for stand
interface cable
