TECHNICAL SPECIFICATIONS
The technical specification details of EM6300A are as follows:
MECHANISM TECHNICAL DESCRIPTION
01 Channel Dual, isolated between channels
02 Pulse Amplitude Adjustable, 0-100 mA peak into 500 ohm load each channel.
03 Wave Form Asymmetrical Bi-Phasic Square Pulse
04 Voltage 0 to 50V (Load: 500 ohm)
05 Power source Lithium Battery
06 Size 11.8cm(L) x 6cm(W) x 3.1cm(H)
07 Weight 150 grams with battery.
08 Timer Adjustable, from 1 to 60 minutes or Continuous. Adjustable in 1 minute each
step from 1 to 15 minutes, and 5 minutes each step from 15 to 60 minutes.
Treatment time countdown automatically.
09 Low Battery Indicator A low battery indicator will show up when the battery is low.
10 Operating Condition Temperature: 10°~40°C Relative Humidity: 30%~75%
Atmosphere Pressure: 700Hpa~1013Hpa
11 Remark There may be up to a +/-5% tolerance of all parameters and +/-20% tolerance
of output amplitude & voltage.
The Premier Plus EMS Programmes P13-P24
NO PROGRAMME SYN/ALT Rate Width Ramp On Time Off Time Timer
(Hz) (s) (sec) (sec) (sec) (min)
13 ACL repair/joint protection back muscle SYNCHRONOUS 35 300 3 8 24 20
14 Spasm small muscle SYNCHRONOUS 80 300 3 10 5 20
15 Spasm Postoperative SYNCHRONOUS 80 250 2 8 4 20
16 Arthroscope SYNCHRONOUS 25 200 2 6 30 15
17 Disuse atrophy SYNCHRONOUS 35 300 2 5 15 30
18 Shoulder Subluxation SYNCHRONOUS 50 300 5 15 50 15
19 Range of motion mules re-education of hips SYNCHRONOUS 40 250 3 6 21 30
20 Muscle training SYNCHRONOUS 50 250 2 10 10 20
21 Muscle training SYNCHRONOUS 50 250 2 14 14 20
22 Muscle training SYNCHRONOUS 35 400 2 10 10 20
23 Muscle training ALTERNATE 50 250 2 10 10 20
24 Muscle training ALTERNATE 50 250 2 14 14 20
